Бесшовная УФ стойкая жаккардовая предварительно Изолированная гофрированная труба из нержавеющей стали

Product Overview

Description

Seamless UV resistant jacketing  pre insulated corrugated stainless steel tube

Item Name	Seamless UV resistant jacketing  pre insulated corrugated stainless steel tube
Size	DN12,DN16,DN20,DN25
Material	stainless steel
OD & ID	16mm*12mm,20mm*16mm,25mm*20mm,32mm*26mm
Wall thick	13mm,20mm
MOQ	100METERS
Brand	GD-FLEX
Original	China





Introduction



GD-FLEX pre insulated solar hose ( pre insulated corrugated stainless steel tube) only require 1 step to finish the Solar Water Heater Pipe Installation.



GD-FLEX pre insulated solar hose only require 1 step to finish the Solar Water Heater Pipe Installation. Our pre-insualted flexible stainless steel Solar Hose with high temperature EPDM insulation pipe ,Strong Jacketing protection and 2-core temperature sensor cable pre-assembled , it is an ideal choice for your solar thermal system. It realizes the fast pipe connection among solar collectors, the pump station and the water tank. Non-welding required! The system is light weight and space saving, which is easy to handle, even in confined spaces. Flow and return pipes are marked clearly and can be easily distinguished. Smart Design- Break Point does good to installer separate twin pipes into 2 pipes without any destroy of the jacketing protection, meeting the installation demand very well.







Application





Piping systems for solar hot water, heating, heat pumps and air conditioning technology indoor, outdoor or underground piping system.



Structure

Twin pipe: It consisting of high temperature resistance EPDM insulation, 2 x flexible corrugated stainless steel tubes (feed and return), UV-resistant, Silicone-sensor line, seamless jacketing protection.



Single pipe It Consisting of high temperature resistance EPDM insulation, 1 x flexible corrugated stainless steel tube, UV-resistant, seamless jacketing protection.



Single pipe with  Temperature Sensor Cable It Consisting of high temperature resistance EPDM insulation, 1 x flexible corrugated stainless steel tube  (feed and return), UV-resistant, Silicone-sensor line, seamless jacketing protection.



Twin Solar Hose Features



Specifically designed for solar thermal panels.:

1. Seamless UV resistant Jacketing,pasd 500 hours UV resisitant test(the standard is 150 hours)
2. Easy to distinguish the feed pipe and return pipe. Our Sensor cable is on one side of the twin pipe, which is easy to distinguish the feed pipe and return pipe line
3. Flexible high-grade corrugated stainless steel tube ,Maximum pressure up to 17.5 bar, 1050°C annealing heat treatment, food grade
4. 100% Genuine EPDM insulation pipe. closed cell foam structure; free of PVC and non- CFC. Work Temperature Max to 175°C
5. Coil length is available in 1,2,5,10, 15,20,30,60 meters. Other length is available upon customer's request
6. Each Twin pipe can be separated from the break point into 2 complete single pipes according to the installation requirements.no destory the seamelss UV resistant jacketing.
7. Save time, Save space ,Save cost,  gd-flex pipe make you pipe installation fast ,easy and reliable.

               Twin/Single pre insulated solar flex pipe performance data



DN	SS-tube		Insulation Pipe			Supplied lengths (M)	Fitting (BSP/NPT)	with/without control cable
	ID/OD	Material	Material	Thickness (mm)	Temp
DN 12	12/16	SUS316L SUS304	EPDM	13/20	-200°C to 175°C	5/10/15 /20/30/60	1/2"	2-wire silicone cable
DN 16	16/20	SUS316L SUS304	EPDM	13/20	-200°C to 175°C	5/10/15 /20/30/60	3/4"	2-wire silicone cable
DN 20	20/25	SUS316L SUS304	EPDM	13/20	-200°C to 175°C	5/10/15 /20/30/60	1"	2-wire silicone cable
DN 25	26/32	SUS316L SUS304	EPDM	13/20	-200°C to 175°C	5/10/15 /20/30	5/4"	2-wire silicone cable



  Solar flex pipe technical specifications

	INSULATION Material High quality synthetic elastomer (EPDM based) with a complete closed-cell structure. Temperature range From -200°C to +150°C (up to 175 °C operating intermittent.) Flammability :actual burning behavior B1 self-extinguishing, no fireball drops, limited fire spreading Water Vapor permeability u>3000 Thermal Conductivity W/(m.K)  0°C:0.034 24°C:0.037 32°C:0.038 40°C:0.039
	SEAMLESS JACKETING PROTECTION Material Seamless UV resistant and high mechanical resistant PE-HD jacketing UV Resistance Excellent UV and weather resistant properties. 500 hours UV risistant test,excellent performance jacketing color standard:black;    red,blue,white ,other color available upon your requirement
	CORRUGATED STAINLESS STEEL TUBE Material SUS304/SUS316L OD * ID 16mm*12mm(DN12,connection fitting 1/2") 20mm*16mm(DN16,connection fitting 3/4") 25mm*20mm(DN20,connection fitting 1"   ) 32mm*25mm(DN25,connection fitting 5/4") work temperature -200 °C  to +600 °C work pression DN12 17.5bar DN16 15bar DN20 12bar DN25 10bar heat treatment 1050°C high temperature annealing heat treatment, food grade, inner and outer wall both are bright
	TEMPERATURE SENSOR WIRE Temperature Range from -200°C to +200°C Flexible Copper 0.75mm2 Wire Insulation Silicon Rated Voltage 300/500 V Electric Resistance
