Plate Suspension Magnetic Separator for Conveyor Belt

Product Overview

Description



Permanent Overhead Separator for Converyor Belt



can remove 0.1~30kg iron materials with more than 10 years service time of inner permanent magnet. When lots of iron materials are attracted onto the bottom of Suspension Magnet , use non-magnetic scraper or gloves to remove them manually. It is suitable for continuous working and low iron-content situation. Besides the current type for 500mm - 1400mm width belt, we could also manufacture according to your specific needs. Ferrite magnetic system and Rare Earth magnetic system are available for Conveyor Magnet .





Typical Applications are:



1. Removal of ferrous materials in mining operations.

2. Separation of ferrous contamination in quarries.

3. Magnetic extraction of ferrous particles in wood processing.

4. Recover ferrous metal in waste management process.



Typical Suspension Permanent Separator wiht Ferrite Magnetic System



Type	Belt Width (mm)	Suspension Height (mm)	Rated Height Magnetic Force	Pulling Capacity	Size (mm)			Weight Kg	Magnetic System
					L	W	H
QJRCDK-50	500	170	45mT	0.1-30kg	598	488	209	350	Ferrite
QJRCDK-65	650	180			728	573	219	450
QJRCDK-80	800	180			828	658	219	600
QJRCDK-100	1000	200			1028	658	219	750
