Double Swing in Gliding Bus Door System

Product Overview

Description

Double Swing-in Gliding Bus Door System:
1. Pneumatic
2. Swing-in
3. Double Leaves
4. Buses/coaches

 Double Swing-in Gliding Bus Door System is new opening/closing mechnsim, the power propellers are mounted above the door so as to save space. It is novel and beautiful in structure, easy and safe in operation. In the mean time, it has many advantages as anti-clamp, governingspeed, anti-vibration and guarding against other interference. It mainly applies to luxury bus and motorbus.



Main technical specification:

Ambient temperature	-40°C~+80°C
Air pressure	0.4Mpa~0.8Mpa
Working voltage	DV24V(12V)
Driving force	2000N(0.7Mpa)
Endurance	1000000 times



We passed the Certifications: ISO9001,ISO/TS16949,ISO14001
