Rubber Foam Insulation sheet for AC Pipping Sound Insulation

Product Overview

Description





Characteristics

• Environment friendly: no chlorine and fluoride, confirm to the requirements of ISO14000 International Environmental Certification, so in installation or use it will not produce any pollutant to harm human;


• Low heat conductivity: Rubber plastic insulation board is high-quality insulation and energy-saving material, and is the invincible opponent of cold insulation, thermal insulation and anti-condensation. Its low and stable heat conductivity makes an excellent thermal insulation effect to any thermal medium;


• Good fire proof performance: Rubber plastic material confirms to the National Standard GB8624, Building Materials Combustion Performance Analysis has tested and graded it as GB8624B1 Flame retardancy material;


• Long service life: Rubber plastic has properties of weather resistance, cold resistance, heat resistance, dry resistance, damp resistance, UV resistance, ozone resistance, ageing resistance for 25 years, deformation resistance, and long service life under maintainance-free;


• High-end appearance, neat and beautiful: Rubber plastic has characteristics of high elasticity, smooth surface, and soft texture, even if installed on bend, tee joint or valve such kind of irregular parts, it will still maintain complete and beautiful; its appearance doesn’t need decoration, even if suspended ceiling is not installed, its high-end effect can still be ensured;


• Easy and convenient to install: Because of its soft material and no need of other Auxiliary Stratotype, it’s easy to install, and for the installation of pipelines, it can be adjustable according to the installation of pipelines.



Technical Index

Item		Unit	Performance Index
			0		Ⅰ		Ⅱ
			Board	Pipe	Board	Pipe	Board	Pipe
Apparent Density		Kg/m3	65-70		60-65		60-65
Combustion Performance		--	Grade	0	Grade	B1	Grade	B2
			Oxygen Index	≥40	Oxygen Index	≥32	Oxygen Index	≥28
			Smoke Density	≤70	Smoke Density (SDR)	≤75	Smoke Density (SDR)	≤75
Heat Conductivity(Average temperature)		W/m·k	≤0.034
Water Vapor Permeability	Coefficient	G/m, s, p, a	≤10×10-10 ≤7×10-10 ≤4.5×10-10
	Factors	--	≤10×10-10 ≤7×10-10 ≤4.5×10-10
Water Absorption Ratio in Vacuum		%	≤10
Dimension Stability (105±3, 7d)		%	≤10
Tear Strength		N/cm	≥3.0
Compression Resilience Ratio (Compression Ratio 50% Compression Time 72h)		%	≤70
Ozone Resistance (Ozone Partial Pressure 202Pa 200h)		--	No chap
Aging Resistance (150h)		--	Slight corrugation, no flaw, no pin hole, no deformation
