75Cr1steel/1.2003 steel/8TCr carbon Tool Steel Round Bar

Product Overview

Description



GB T8Cr/75Cr1/DIN 1.2003 Tool Steel





GB T8Cr/75Cr1/DIN 1.2003 tool steel stockholders and suppliers, delivering to the whole of World. Huangshi Youli Steel/Huangshi Smooth Industry and Trade are stockholders and suppliers of round bar, flat bar, plate and block. As an alloy tool steel grade GB 75Cr1/DIN 1.2003 is commonly supplied in the hardened and tempered condition with a supply hardness of approximately 200HB. This steel grade gives an excellent polished finish and is one of the most widely accepted specifications for mandrels,punches,crushing tools,razors. This grade gives excellent wear resistance and better hardening. This steel is also suitable for small tools due to a Rockwell hardness of 47-51 HRC.



We welcome export enquiries for tool steel. Contact our sales office and consult our shipping policy for further details.





Form of Supply



Huangshi Youli Steel/Huangshi Smooth Industry and Tradel are stockholders and suppliers of GB T8Cr/75Cr1/DIN 1.2003 tool steel round bar, flat bar, plate and block. Diameters can be sawn to your required lengths as one offs or multiple cut pieces. Rectangular pieces can be sawn from flat bar or block to your specific sizes. Ground bar can be supplied, providing a quality precision ground bar to tight tolerances.



Contact our experienced sales team who will assist you with your GB T8Cr/75Cr1/DIN 1.2003 tool steel enquiry.



 Plate



 Flat



 Diameter

 Sheet

 Wire







Applications



This tool steel grade is ideally suited for the production of plastic moulds. Typical applications include die holders, zinc die casting dies, backers, bolsters and injection moulds. The versatility of GB T8Cr/75Cr1/DIN 1.2003 tool steel with its high tensile characteristics enables uses for a variety of other applications such as shafts, rails and wear strips



Analysis

Carbon	0.70-0.80%	Chromium	0.30-0.40%
Manganese	0.60-0.80%	Molybdenum	-
Sulphur	0.03% max	Silicon	0.25-0.50%
Phosphorous	0.03% max	Vanadium	-
Tungsten	-



Forging



Heat the steel slowly, allowing sufficient time for it to become heated through. Begin forging at 800-1000°C. Annealing at 700-720°C reheating if necessary. After forging, hardness is below 200HB.



Annealing



Heat uniformly to 700-720°C. Soak well, cool slowly in the furnace.



Stress Relieving



When dies are heavily machined, we recommend stress relieving just before finish machining in order to relieve machining strains. Heat to 180-200°C. Soak well and allow to cool in the air.





Hardening



Heat uniformly to 700-720°C until heated through. Quench in water.



Tempering



Heat uniformly and soak at the tempering temperature for at least one hour per 25mm of section. Allow to cool in still air.







Temperatur	100	200	300	400	500	600
e [°C]
Hardness	51	50	48	46	42	36
[HRc]
Tensile	1730	1670	1570	1480	1330	1140
[N/mm²]

Carbursing / Case Hardening



In order to obtain maximum surface hardness, moulds machined from GB T8Cr/75Cr1/DIN 1.2003 tool steel may be case hardened, which can achieve a surface hardness of 43 to 66 HRc.









Heat Treatment



Heat treatment temperatures, including rate of heating, cooling and soaking times will vary due to factors such as the shape and size of each steel component. Other considerations during the heat treatment process include the type of furnace, quenching medium and work piece transfer facilities. Please consult your heat treatment provider for full guidance on heat treatment of GB T8Cr/75Cr1/DIN 1.2003 tool steel.





Quality Assured Supply



GB T8Cr/75Cr1/DIN 1.2003 carbon steel is supplied in accordance with our ISO 9001 : 2008 registration.
