2022 Expanded Graphite 9080200 and 9550250

Product Overview

Description

Expanded graphite is also named flexible graphite. Expanded graphite is a kind of new carbon material with graphite as raw material, natural graphite, sulfuric acid ,nitric acid and other chemical reagents role evolved after heating, the formation of intercalation compounds; after high temperature treatment, the rapid decomposition, after the second expansion, the volume can be increased to 400 times as the original, so it called the expanded graphite. It is porous, strong adsorption, elastic. Temperature range is wide, between -200-3600 °C. Can withstand the neutron, gamma, beta - ray exposure. Work in high temperature, high pressure or radiation condition, no decomposition, deformation or aging. It with stable chemical properties. This product is widely used as a fire sealing element, flame retardant, fire brick, also can be used as thermal insulation, sound insulation and shock, lining material, is a novel promising engineering materials.



Main Application: Additive of Metallurgical thermal insulation material ,the raw material of flexible graphite paper, cell adsorption material; lubricant additive; fire extinguishing agent additive

Properties:

It has good expansibility, its manufactured goods has the advantages of high temperature resistance, heat insulation, lubricating and chemical stability.



Expansion Rate: During 150ml/g to 350ml/g.





Technical indexes:







Brand No	Volatile (%)>≠	Ash (%)>≠	Moisture (%)>≠	PH Value	Particle Size Screen Oversize	Expansion Multiple
9950300	13	0.7	2.5	3-7	70	300
9950250	13	0.7	2.5	3-7	70	250
9950200	13	0.7	2.5	3-7	70	200
9950150	13	0.7	2.5	3-7	70	150
9950100	13	0.7	2.5	3-7	70	100







Specif- ication	Fixed Carbon (%)	Ash (%)	Volatile (%)	Expansion Ratio (ml/g)	Sulfuric acid content		PH Value	Moisture (%)	Particle Size Screen Oversize
					Before Expansion (%)	After Expansion (%)
Kp32	90-99.9	≤8.0	≤12	200-400	≤2.2	≤1500	3-7	≤1.0	≥80
Kp50				200-350
Kp80				150-250
Kp100				100-200







According to the customer request adjustment index.
