Hdpe Hydraumatic Chair Garbage Trash Can Injection Molding Machine Thermoplastic
- Category: >>>
- Supplier: Zhangjiagang Mars Packing Machinery Co. Ltd.
Share on (1453374141):
Product Overview
Description
Hdpe Hydraumatic Chair Garbage Trash Can Injection Molding Machine Thermoplastic
Name of item | UNIT | A | B |
Screw Diameter | MM | 50 | 55 |
Screw L/D Ratio | L/D | 22 | 20 |
Shot Volume | Cm3 | 461 | 558 |
Shot weight (ps) | G | 420 | 508 |
| Oz | 15 | 18 |
Rate of injection (ps) | g/s | 154 | 187 |
Plasticizing Capacity (ps) | g/s | 32.5 | 39.2 |
Injection pressure | Mpa | 212 | 175
|
Screw Speed Range | Rpm | 3-200 | |
Mould Clamping Force | KN | 2280 | |
Opening Stroke | MM | 490 | |
Space Between tie and Bars | MM | 520*500 | |
Max. Mould Thickness | MM | 540 | |
Min. Mould Thickness | MM | 200 | |
Ejector Stroke | MM | 160 | |
Ejector Force | KN | 61 | |
Ejector point | PC | 5 | |
Max. pump pressure | Mpa | 16 | |
Motor Power | KW | 18.5(22) | |
Heating Power | KW | 12.5 | |
Oil Tank Capacity | L | 310 | |
Machine Size (L*W*H) | M | 5.1*1.5*1.95 | |
Machine Weight | T | 7.2 | |
