Structure | OP( primer)/Print Layer/Alu/HSL(VC agglutinate layer) |
Specification | Width: ≤610mm OP:1g+/-0.5g AL:20-30micron VC:3-8g Lenghth:1500M Per roll or upon on client's reguirement. Colors: printed or unprinted Inner core: 76mm Outer core:240mm Treatment: coating Type: Hard |
Feature | Excellent properties such as of anti-oxygen, moisture-proof, leak-proof, carry-home, anti-pollution, etc. Adopting hard anodized aluminum as cover material, it is easy to break aluminum foil to take out the drugs by pushing the cover. Adopting heat-seal coating material, which cannot be stripped, it can be bonded with all kinds of plastic-based materials. |
Application | Heating sealing with PVC/PVDC or Cold forming foil to pack pills, capsules and tablets |

STRUCTURE | UNIT | ALU 20 | ALU 25 | ALU 30 |
OP Lacquer | g/m2 | 1.5+/-0.5 | 1.5+/-0.5 | 1.5+/-0.5 |
Alu Foil | micron | 20+/-1 | 25+/-1 | 30+/-2 |
VC Lacquer | g/m2 | 3.5+/-0.5 | 3.5+/-0.5 | 3.5+/-0.5 |
TOTAL THICKNESS | micron | 24+/-1 | 30+/-1 | 35+/-1 |
TOTAL WEIGHT | g/m2 | 59+/-0.5 | 72.5+/-0.5 | 85+/-0.5 |
OP LACQUER - I | OP LACQUER - II | OP LACQUER -III | OP LACQUER - IV | |||||
SOLVENT PRINTING INK AS ACETIC ETHER | UV PRINTING INK | ETHANOL PRINTING INK | SCREEN PRINTING INK | |||||
SPECIAL REQUIREMENTS FOR VC LACQUER | ||||||||
VC LACQUER (g/m2) | 4.5+/-0.5 | 5.5+/-0.5 | 6.5+/-0.5 | 4.5+/-0.5 | ||||
