KOREA EGI Steel (Electro Galvanized Steel Sheet)

Product Overview

Description



Korea Ara Corp's Electro-Galvanized Steel Sheet/Coil (it is not Chinese Product)  is a product, which has an enhanced corrosion-resistant characteristic through an electrolytic galvanizing process to Cold Rolled Steel.





PRODUCT FEATURES



   Formability - Unlike Hot-Dipped Galvanized Steel, the base metal of the Electro-Galvanized Steel

is less affected by the  heat and therefore, it is able to retain its formability.



   Paintability - Free from any spangles and pin-holes, the Electro-Galvanized Steel has a flawless

surface that is most  ideal  for any type of painting.



   Corrosion Resistance - The EGI's evenly coated zinc enhances its resistance to any type of corrosion.

(Additional surface treatments are available for further enhancement of corrosion resistance.)



   Weldability - Among all coated steel, the EGI has the highest weldability due to minimum

amount of zinc being coated.



Chromium-free AFP Products



.Application of hexavalent chromium alternative material

- Develop trivalent chromium, a stable material, as the main component

(Add etching agent, reducing agent, level agent, etc.) : Cr-free, non-toxic chromate

- Superior corrosion resistance: secure same corrosion resistance level of existing products



.Environment-friendly products

- Environment-friendly products harmless to humans and environmental pollution preventive

- Actively corresponds to environmental regulations of Europe and other leading countries





Specification & Available size range



Item	Figure	Coating	Quality	Surface
Thickness	0.25 ~ 2.4mm	05/05 G/SQ MTR	SECC	PHOSPHATED
Width	600~ 1,524mm	10/10 G/SQ MTR	SECD	CHROMATED / CHROME FREE
Sheet Length	600 ~ 5,000mm	20/20 G/SQ MTR	SPEC	OILED
Coil Inner Diameter	508 / 610 mm	30/30 G/SQ MTR	SECEN	ANTI FINGER







An order of inquiry should be accompanied by the following information.



1. Size : Thickness / Width / Length ( in case of Cut Lengths).

2. Specification requirement :  Coating designation or Wt / Type of coating & surface treatment

                            Coil I.D / Packing Weight.

3. Quantity.

4. Intended use

5. Packing and marking requirement.

6. Delivery Requirement.

7. Required inspection, if other than mill inspection.

8. Other pertinent information.
