Product Overview
Description
Chinese Supplier Mini 12 volt DC Servo Motor 24v DC Servo Motor Price
| CONSTAR MICROMOTOR | ||
 |  |  |
| PRECISION DC CORELESS MOTOR | BRUSHLESS DC MOTOR | SERVO MOTOR |
 |  |  |
| GEARMOTOR | STEP MOTOR | MINI CORELESS MOTOR |
Applications
Precision control fields like medical instrument,industrial robot and so on.
Specifications
Motor Characteristics
| 1 | Voltage | V | 12.0 |
| 2 | Terminal resistance | Ω | 28.0 |
| 3 | No-load speed | rpm | 11500 |
| 4 | No-load current | mA | 10 |
| 5 | Stall torque | mNm | 4.17 |
| 6 | Stall current | mA | 429 |
| 7 | Nominal torque | mNm | 1.0 |
| 8 | Nominal speed | rpm | 8100 |
| 9 | Nominal current | mA | 140 |
| 10 | Max. output power | W | 1.26 |
| 11 | Max. efficiency | % | 74 |
| 12 | Back-EMF constant | mV/rpm | 1.02 |
| 13 | Torque constant | mNm/A | 9.73 |
| 14 | Speed/torque gradient | rpm/mNm | 2757 |
| 15 | Rotor inertia | gcm2 | 0.09 |
| 16 | Weight | g | 8 |
| Encoder Characteristics | |||||||
| 1 | Number of channels | 2 | 3 | ||||
| 2 | Counts per turn | cpt | 16, 32, 64 | 16, 32, 64 | |||
| 3 | Supply voltage | V | 5.0 (5.0) | 5.0 (5.0) | |||
| 4 | Max. speed | rpm | 30000 | 30000 | |||
| 5 | Phase shift | °e | 90±45 | 90±45 | |||
| 6 | Output signal | TTL | TTL | ||||
| 7 | Diameter | mm | 10 | 10 | |||
| 8 | Length | mm | 8.5 | 8.5 | |||
Options
Lead wires length, Shaft length, Special coils, Gearheads, Encoder channels, Encoder counts per turn
Product Show
Customized Motor
CONSTAR MICROMOTOR specialize in design, custom and manufacture electric motors,including DC Coreless Motor, Sonic Motor, Brushless DC Motor, Gear Motor, Servo Motor, DC Core Motor and Mini Step Motor.All of them can be fully and easily customized . We committed to offer high quality, high performance, cost effective options to meet customers specific demands. Choosing to customize one of the motors in our Product Categories now!
Outline Drawing
Other Item
 |  |  |
| 8mm Mini Servo Motor | 16mm Dc Servo Motor | 25mm Gear Motor With Encode |
| Series | Dimension (mm) | Voltage (V) | Termanal resistence (Ω) | Torque Constant (mNm/A) | Number of channels | Counts per turn (cpt) |
|---|---|---|---|---|---|---|
| 1043N5M | Φ10*43 | 12 | 28 | 9.73 | 2(3) | 16--64 |
| 1653N5M | Φ16*53 | 6 | 7.1 | 6.36 | 2(3) | 16--64 |
| 1654N5C | Φ16*54 | 12 | 13 | 7.43 | 2(3) | 16--64 |
| 228105C | Φ22*81 | 24 | 19.6 | 29.66 | 2(3) | 16--1024 |
