semi auto with factory price Small Toilet Paper Making Machine
- Category: >>>
- Supplier: Jubao Technical Machine Co. Ltd. [Fujian China]Jubao
Share on (1541470893):
Product Overview
Description
HC-TR small toilet paper making machine
Main features of Small Toilet Paper Rolling Machine
1.Tension volume to meet the high-low base paper production.
2. Spiral cut, cutter body rigidity, running fast, no noise, no vibration.
3. Electronic Count Control, the product weight unity.can produce with core or without.
4. Steel to rubber roller rolling pattern, pattern track obvious; can choose rubber to roller or wool to roller and reliabl service life.
5. Special saw belt, sub-cut planing, saw with a grinding, easy to operate.
Technology parameters of jumbo roll toilet paper machine
Model | 1092 | 1575 | 1760 | 2200 | 2500 | 2800 |
Max parent roll width | 1300 | 1750 | 2000 | 2150 | 2400 | 2700 |
Max. parent roll diameter | Standard 1100mm unless otherwise specified | |||||
Qty of unwind stand | 3 stands (pls specify when order) | |||||
Core inner dia. of parent roll | Standard 3'(76.2mm) unless otherwise specified | |||||
Data setting | PLC | |||||
Operate speed | 0-150M/MIN | |||||
Outer dia. of finished log | 90-150mm | |||||
Core inner dia. of finished log | 25-50m | |||||
Mechanical driving | Driving by Stepless gear box | |||||
Air -system | 3HP air compressor, min. pressure 5kg/cm2pa ( provide by user) | |||||
Main driving | Electromagnetism 4.5KW 380V,50HZ | |||||
Dimensions | 5.2*2*1.7 | 5.2*2.4*1.7 | 5.2*2.6*1.7 | 5.2*2.8*1.7 | 5.2*3.1*1.7 | 5.2*3.34*1.7 |
Weight | 1.5T | 2T | 2.1T | 2.4T | 2.7T | 3T |
Perforating Size | 90mm-500mm(Other Sizes Can be Specified) | |||||
Optional Device | ||||||
Paper Unwind Stand | 1-3 Stands (The Qty. of Raw Paper Rolls to be Specified)(To be Ordered) | |||||
Gluing | Gluing On Convexity(To be Ordered) | |||||
Decorative Gluing System | Subject To The Embossing Pattern(To be Ordered) | |||||
Embossing unit | Single Embossing , Double Embossing ,Steel To Steel ,steel to felt , steel to woolen, steel to rubber , Pneumatic Embossing (To be Ordered) | |||||
Some Electric Assembly Parts | |||
No | Parts Name | Brand | Original Place |
1 | Touch Screen | WEINVIEW | Taiwan |
2 | PLC | Delta | Taiwan |
3 | Inverter | Delta | Taiwan |
4 | Frequency Panel | Delta | Taiwan |
5 | Switching Power Supply | Ming-Wei | Taiwan |
6 | Air switch | LS | Korea |
7 | Relay | OMRON | Japan |
8 | Contactor | LS | Korea |
9 | Thermal Overload Protection | LS | Korea |
Flow
Unwind — drawing paper — embossing — gluing — pressing — perforating — winding — cutting — trimming — sealing — sending
Services Terms:
1.We provide to arrange customer’s factory, complete line and material purchasing or guiding
2. Follow-up service of product: we will notice you since the product leaves the factory.
3. After complete of engining: we help our customers train fountain equipment operator for free.
4.Error treatment: the customer service department will take action immediately when they receive any call and provide professional repairer to help you solve your problems as soon as possible.
About Us:
Established in 2006, Hi-Create machine co.ltd specializes in the design and manufacture of paper machine products.
With an ce,sgs:certified manufacturing factory which covers about 15000 square meters, we employ about 20 high quality talents and about 115 experienced workers Who make about 80 sets of paper machine products monthly. Moreover,2 to 3 new models will be released by our 8 experienced engineers.
Our company was the first to produce and export portable paper machine to Southeast Asia and have used our experience to extend our business to include North America, Europe, South America and Australia,Africa,Southeast Asia/Mideast.
Company Information
 |
 |
 |
 |
 |
 |
 |
FAQ
1. Q: How about the quality?
A:We guarantee them for 1 year generally, but our customer used our machines for many years without problem.
2. Q: How long is your guarantee?
A: One year(Calculated from the equipment arrives at the customer’s side.).
If there is any problem within guarantee period (excluding cased by human's wrong action), we will send you spare parts for free.After this period we will definitely support you when needed. You will be welcome to contact us with any problem may happen.
3. Q: How should I order? What payment method do you accept?
A: Choose the products what you like, and send inquiry to us for more details (or you can call us, chat with us by online chat software such as TradeManager,Skype; Mobile chat software such as Whatsapp,Line,Viber,Wechat,etc.). After confirming all details and signing the contract, you can pay prepayment, then we produce machines after receiving prepayment. We deliver these machines by ship according to our agreement. We send the documents to you after shipment. We accept payment by T/T generally, and also accept L/C
4.Q: How can I get to your company?
A:We are located in Quanzhou City, China.
You can get a flight to xiamen International Airport.We will go to airport to pick you up. It takes around one hour from airport to our office. You may also come to our city by High Speed Railway train, we will go to train station to pick you up.
5.Q: Lead time?
Within 5-10 days after receive payment
6.Q: Packing?
PE film packing or fiber wooden boxes, suitable for International transportation
If you want to know more information about our products welcome to contact us in any time, And welcome to our factory!
