Пластинчатый пастеризатор/пластинчатый теплообменник Пастеризатор

Product Overview

Description

Plate Pasteurizer/plate type pasteurizer/plate heat exchanger pasteurizer







1.Production Capacity: 1000L/H

2.Inlet Temperature:5 to 30 (adjustable)

3.Outlet Temperature:2 to 30(adjustable)

4.sterilizing Temperature:70°C(adjustable)

5.Holding time:4-15sec (adjustable)

6.All can adjust as customer requirement

7.Size:2000mm*1400mm*2000mm

Main Fittings: 3 stage plate heat exchanger,Automatic Simens PLC control,material

pump, balance barreled, heating water system, Temperature Controlling and record

device, electric elements of controlling system



Working condition
Material(Milk)  Capacity		1T/h	Inlet temperature		20-30°C			Steam pressure	0.5~0.6MPa
Cold Water Temp		2°C
Design Requirement
Material Sterilizing temperature	70°C			Holding time		15 sec	Outlet Temperature			2-30°C
