TRIACS disc type KS200 KS300 KS50 ,KS800 KS1000 disc TRIACS
- Category: >>>
- Supplier: Tianjin Century Electronics Co. Ltd.
Share on (1568559847):
Product Overview
Description
TRIACS -- Disc Type
Model | VDRM VRRM
V | IT(AV)
@TC =85℃
A | VTM | IGT
mA | VGT
V | IDRM IRRM
mA | ITSM
@10ms
A | dv/dt
V/μs |
dv/dt(c)
V/μs |
Rthjc
℃/W | Outline | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
V
| @ITM
A | |||||||||||
KS200 | 100~1800 | 200 | ≤2.4 | 600 | ≤350 | ≤3.5 | ≤25 | 1.7 | ≥50 | ≥4 | 0.120 | T6 |
KS300 | 300 | 900 | ≤30 | 2.5 | 0.055 | T7 | ||||||
KS500 | 500 | 1500 | ≤400 | ≤4.0 | ≤30 | 4.0 | ≥10 | 0.043 | T9 | |||
KS800 | 800 | 2400 | ≤50 | 6.8 | ≥200 | 0.027 | T11 | |||||
KS1000 | 1000 | 3000 | ≤50 | 8.5 | 0.022 | T11 |
