CE certificated water cooled chiller/water Chilling Plant

Product Overview

Description

CE certificated water cooled chiller/water Chilling Plant





Injection Industry

Golden chiller can accurately control the temperature of mold which can improve the quality and production rate.



Electronic Component Industry

Golden chiller can stabilize the molecular structure of electronic component inside. This can improve the FTQ and product time.



Machinery Industry

Golden chiller can cool down the oil for the machine and stabilize the oil temperature and pressure. It’ll extend the useful life of oil. And it can also improve mechanical lubrication efficiency.



Electroplating Industry

The temperature of electroplate can be controlled by our chiller. It can improve the density and smooth of electroplate and production efficiency.



Food & Drink Processing Industry

The temperature of processed food and drink will be too high to be packaged. Golden chiller can cool it down through food grade stainless steel heat exchanger.



1.  World famous scroll compressor: Copeland,Dakin,Sanyo.



2.  Adopt stainless stell water tank.



3. We have own processing department of red cooper piper and professional welding technician team for weld, completely eradicate any concurrency problems of  weld  break.



4.  Cooling capacity:9.3-142.2KW



5.  Support kinds of  refrigerants,R22/R407C/R410A



6.  We would like to production non-standard unit accoridng to client requirement.





Model  HLLA ~			03SI	05SI	08SI	10SI	12.5SI	15SI	20DI	25DI	30DI	40TI	45TI
Rated Cooling Capacity		×1000 kcal/h	7.9	12.8	20.8	27.9	32.3	40.8	55.7	64.7	81.5	97.0	122.3
		KW	9.2	14.9	24.2	32.4	37.6	47.4	64.8	75.2	94.8	112.8	142.2
Input Power (KW)			3.85	5.55	8.15	10.4	12.0	16.0	20.1	22.5	31.2	33.7	45.7
Comp. Input Power×Qty.  (KW)			2.6	4.3	6.35	8.1	9.3	12.5	8.1×2	9.3×2	12.5×2	9.3×3	12.5×3
Chilled Water Pump Power  (KW)			0.75	0.75	1.1	1.1	1.5	1.5	1.5	1.5	2.2	2.2	2.2
Comp. Current (A)			6.8	10.5	14	17.5	20	25.6	33.8	37.2	49.8	55.8	72.6
Power Supply			3φ-380V-50HZ
Safety Protection			Phase reversion protection, Phase lack protection, Overload current protection, Discharge air temp.  protection, Low & High pressure protection, Low temp.  protection, Water flow protection.
Number of Refrigeration Circuit			1			2	1	3	2		3
Capacity Control (%)			0, 100			0, 50, 100	0, 100	0, 33, 66, 100	0, 50, 100		0, 33, 66, 100
Refrigerant			R22
Condenser			Ripple Aluminum Fins around Cooper Pipe
Power lnput of Fan (KW)			0.5	0.5	0.7	1.2	1.2	2.0	2.4	2.4	4.0	3.6	6.0
Evaporator			Pipe Coil Type			Pipe Coil Type  (Shell & tube type optional but without water tank)
Water Side Max Pressure (MPa)			-			1
Dia.of Pipe to Evaporator (inch)			1"		1-1/2"		2"				2-1/2"
Chilled Water Flow (L/m)			26.4	42.7	69.4	92.9	107.8	135.9	172.0	194.8	272.2	292.2	408.3
Evaporator Water Pressure drop (kPa)			-		17	23	28	30	28	28	32	32	31
Running Noise dB(A)			72	72	73	75	75	75	75	75	75	75	75
Tank Volume (L)			50	70	120	200	200	270	350	350	420	510	510
Total weight (Kg)			130	170	430	480	510	560	840	880	980	1130	1280























Dongguan Golden Refrigeration Equipment Co., Ltd. is a modern large enterprise, which integrates technology, industry and trade. we are a professional enterprise that provides central A/C, refrigeration plant, eletromechanical device, electric equipment and electronics, as engineering design and installation service. Golden takes an area of over 100,000m2  with an asset of more than 100 millions and empolyee of more than 500 persons, and its has 5 branch companies in the rest of China.
