300mm x 72T Circular Saw Blade for Cutting plywood

Product Overview

Description

1.Introduction

TCT circular saw blades are for cutting wood, aluminium, hard wood and so on.

We are proud to introduce our woodworking saw blades which are the highest

standards of precision required for fine woodworking and finish carpentry.

Engineered with oversized, high quality carbide, the new Marples Woodworking Series

saw blades provide the extended life and flawless finish professional woodworkers

and finish carpenters demand.





2.specification

1. Sandwich Soldering Flake from BRAZETEC GROUP, Germany

2. High bending resistance makes carbide tip difficult to be broken.

3. Internal stress removed , deformation will not happen after long time using.

4. The accuracy of the front, behind and side angle up to 0.035mm

5. Over ten years experience, free consult service









1.Material: Body:45#,50#,65Mn....

Carbide Tip:YG8,YG6,YG6X,......

2.Teeth: ATB (alternate top bevel ) teeth

Flat tooth

3. Application: wood, man-made board, chipboard.

4. Size:



Outer Dia(mm)	Kerf/Body(mm)	Teeth	Arbor size(mm)
110	1.1/1.2	30/40	20/16
180	1.3/1.4/1.6	40/60	20/16
200	1.5/1.6	60/80	30/25
230	1.5/1.6/1.8	40/60/80/100	30/25
250	1.7/1.8/2.25	40/48/52/60/80/100/120	30/25
300	2.0/2.25	40/60/80/100/120	30
350	2.2/2.3	40/60/80/100/120	30
400	2.2/2.3	40/60/80/100/120	30
