1000L Milk Cooler Tank/Milk Storage Tank
- Category: >>>
- Supplier: Shanghai Chun Nuo Machinery Co. Ltd.
Share on (1600051178157):
Product Overview
Description
Product Description
1000L Milk Cooler Tank, Milk Storage Tank
1. The integral direct-cooling type 1000L milk cooler tank, hereinaffter reffered to as the refrigerating tank, is mainly used for freshness retaining, cooling and storage of liquid materials in such fields as meadow, milk station, slaughter house, dairy products, food, beverage, medicine, etc.
2. Milk storage tank is mainly composed of tank body, blender, refrigerating unit and electric control, etc.
3. Milk cooling tank is completely made of SUS304 stainless steel and subjected to precise polishing treatment so that dirt is not easily accumulated in it and it is easy to be cleaned with corrosion resistant performance. The heat preservation layer of the tank is filled by hard foam plastic of low heat-conducting coefficient and light weight to achieve a good heat preservation performance.
4. 1000L milk tank price is based on product capacity, compressor brand, and main accessories brand, etc.
Detailed Images
1000L Milk Cooler Tank Proposal
This proposal is just for an example.
Product Name | Specifications |
500L vertical milk cooling tank | 1. Volume: 500L 2. Material: SUS304 3. Dimension:1800*1100*1650mm 4. Air Compressor beand: Copeland (America) 5. Compressor power: 3P 6. Total Power: 2.6KW 7. Refrigerating capacity: 6000Kcal/H 8. Refrigerant: R22 9. Agitator power: 0.75KW, 36rpm 10. Voltage: 220V/50HZ/Single Phase 11. Inner Thickness: 2.5mm 12. Outer thickness: 1.5mm 13. Insulation layer: 50mm, Polyurethane foam |
Size Information
Size information for 1000L milk cooler tank
Model | Volume | Refrigerating capacity | Agitation Speed | Power | Size |
CNZLG-0.5 | 500L | 3500W | 36rpm | 1.5KW | 2200*1350*1150mm |
CNZLG-1 | 1000L | 6900W | 36rpm | 3.0KW | 2750*1150*1500mm |
CNZLG-2 | 2000L | 12000W | 36rpm | 5KW | 3200*1500*1600mm |
CNZLG-3 | 3000L | 19000W | 36rpm | 6.5KW | 3500*1650*1700mm |
CNZLG-5 | 5000L | 34000W | 36rpm | 13KW | 4000*1950*2100mm |
CNZLG-8 | 8000L | 42000W | 36rpm | 16KW | 4800*2400*2400mm |
