Wholesale Japanese exhaust commercial fan wall for favorable price

Product Overview

Description









SCF





Standard models

Model number

Fan blade size(mm)

Voltage(V)

Motor

Max air volume(50/60hz)

Noise level (50/60Hz)

Plug

Net weight

Made / Stock in

Nominal output

Poles

SCF-25DA1

250

Single phase 100

30W

4P

18/21m³/min

44/46.5dB

Yes

6kg

Japan

SCF-30DB1

300

60W

4P

25/28m³/min

46/48.5dB

Yes

7.5kg

Japan

SCF-35DC1

350

100W

4P

37/42m³/min

49/52.5dB

Yes

10kg

Japan

SCF-40DD1

400

150W

4P

49/55m³/min

53.5/56.5dB

Yes

11.5kg

Japan

SCF-N50DE1

500

250W

4P

75/87m³/min

62/67dB

Yes

17.5kg

Japan

 ΟMax air volume are measured in static pressure  0 Pa condition

ΟNoise levels are measured at 1.5m from air outlet

Ο100V models are equipped with thermal protector



Standard models

Model number

Fan blade size(mm)

Voltage(V)

Motor

Rated current (A) (50/60Hz)

Max air volume(50/60hz)

Noise level (50/60Hz)

Plug

Net weight

Made / Stock in

Nominal output

Poles

SCF- 40DD3

400

3phase 200

200W

4P

1.4/1.4

61/72m³/min

59.5/64dB

No

11kg

Japan

SCF-N50FF3

500

400W

6P

2.2/2.4

98/114m³/min

61/64dB

No

20kg

Japan

SCF-T60FG3•

600

750W

6P

5.0/5.5

139/162m³/min

61.5/67dB

No

37kg

Japan

SCF-T75FH3•

735

1500W

6P

9.0/12.5

269/310m³/min

69.5/74.5dB

No

56kg

Japan

SCF-T90FI3•

890

2200W

6P

14.0/14.5

340/390m³/min

74.5/78.5dB

No

91.5kg

Japan

•Mark is models with IE3 high efficiency motor

ΟMax air volume are measured in static pressure  0 Pa condition

ΟNoise levels are measured at 1.5m from air outlet

ΟMax air volume are measured in static pressure  0 Pa condition

ΟNoise levels are measured at 1.5m from air outlet

Ο100V models are equipped with thermal protector
