Pipe Water Supply Polyethylene Pe Plastic Hdpe 16mm 1000mm Wholesale Black Blue Fusion China Socket

Product Overview

Description

Pressure OD (mm)	INCH	Pressure (Mpa)	Thinkness (mm)	Length (M)	Height (cm)	Diameter (cm)
20	1/2	PN1.6MPa SDR 11	2.3	200	30	80
25	3/4	PN1.6MPa SDR 11	2.3	200	40	80
32	1	PN1.6MPa SDR 11	3	200	40	100
40	1 1/4	PN1.6MPa SDR 11	3.7	100	35	100
50	1 1/2	PN1.6MPa SDR 11	4.6	100	45	150
63	2	PN1.6MPa SDR 11	5.8	100	30	177
63	2	PN1.25MPa SDR 13.6	4.7	100	30	177
63	2	PN1.0MPa SDR 17	3.7	100	30	177

Descriptions:

Meets GB/T13663-2000, ASTM D2239, ASTM D2737, ASTM D3035, ASTM F714.
Our high-density polyethylene water and sewer pipe is available in 1/2-inch to 48-inch diameters. The product's physical properties make it applicable to open-trench, horizontal directional drilling, pipe-bursting, and slip-lining installations. It can be manufactured with the color striping to identify application, such as a blue stripe for potable water, a yellow stripe for gas applications and a red stripe for mining applications.



Benefits:

Our HDPE pipe for water and sewer is manufactured for excellent performance and a long life expectancy.
Its butt-fused joints eliminate potential leak points, common at 10 to 20 feet with a ductile iron pipe, for a zero leak rate.
Highly resistant to corrosion and weather, recent studies conclude it will last at least 50 years.
Its lightweight and flexibility make it easy to install, eliminate the need for fittings required with directional changes, and make it highly suitable for use in earthquake-prone areas.
Its high-strength walls give it the highest PE pressure rating, outstanding resistance to SCG, and increased resistance to rapid crack propagation.
The increased working stress rating of high-performance PE resin material makes it a superior choice over steel or ductile iron pipe, especially for the large diameter
pipe sizes.
