Япония, хороший S 6800 6801 6802 6803 6804 6805 6806 6807, индивидуальный шариковый подшипник с глубоким желобом
- Category: Deep Groove Ball Bearings >>>
- Supplier: Shandong Tefule Bearing Co. Ltd.
Share on (1600054579629):
Product Overview
Description
Product Description
Thin wall deep groove ball bearing is the most commonly used rolling bearing. It has a simple structure and is easy to use. Mainly used to bear radial load, but when increase bearing radial clearance, has certain angular contact ball bearing performance, can bear radial, axial joint load. In the high speed and should not be used thrust ball bearings, can also be used to withstand pure axial load. Compared with other types of bearings of the same size, these bearings have small friction coefficient and high limiting speed. However, they are not shock-resistant and are not suitable for heavy loads.
Thin-walled deep groove ball bearings mounted on the shaft, in the bearing axial clearance range, can limit the axial displacement of the shaft or shell in both directions, so can be in both directions for axial positioning. In addition, this kind of bearings also has certain centring ability, when relative to the shell hole tilt 2′ ~ 10′, still can work normally.
Thin wall deep groove ball bearing cage for steel plate stamping wave-shaped cage, can also use engineering plastics, copper entity cage. Large bearings are mostly made of metal entity cage. Sealed bearings according to different use environment can be added to the corresponding bearing special grease.
Thin wall deep groove ball bearings are widely used in model aeroplanes, remote control vehicles, machine tools, motors, water pumps, agricultural machinery, textile machinery and so on. The bearing structure is simple, easy to use, is the production of the largest batch, the widest range of applications of a class of bearings, mainly used to bear radial load. These bearings have small friction coefficient, low vibration and noise, and high limiting speed. According to the user's requirements, can manufacture high-level precision (P6, P5 level), a variety of clearance groups, special vibration, noise requirements (Z1, Z2 or V1, V2) of the thin-walled deep groove ball bearings.
Thin wall deep groove ball bearing cage for steel plate stamping wave-shaped cage, can also use engineering plastics, copper entity cage. Large bearings are mostly made of metal entity cage. Sealed bearings according to different use environment can be added to the corresponding bearing special grease.
Thin wall deep groove ball bearings are widely used in model aeroplanes, remote control vehicles, machine tools, motors, water pumps, agricultural machinery, textile machinery and so on. The bearing structure is simple, easy to use, is the production of the largest batch, the widest range of applications of a class of bearings, mainly used to bear radial load. These bearings have small friction coefficient, low vibration and noise, and high limiting speed. According to the user's requirements, can manufacture high-level precision (P6, P5 level), a variety of clearance groups, special vibration, noise requirements (Z1, Z2 or V1, V2) of the thin-walled deep groove ball bearings.
BEARING NO | OD | ID | Width | Ball Complement | Maximum speed | Weight | ||||
D(MM) | d(MM) | B(MM) | NO | Size | Grease(r/mi | Oil(r/min) | Kg/pcs | |||
S 683 | 7 | 3 | 3 | 7 | 1.2 | 45000 | 53000 | 0.0008 | ||
S 684 | 9 | 4 | 4 | 7 | 1.588 | 39000 | 48000 | 0.001 | ||
S 685 | 11 | 5 | 3 | 8 | 1.588 | 35000 | 45000 | 0.0019 | ||
S 686 | 13 | 6 | 5 | 8 | 2 | 33000 | 42000 | 0.0027 | ||
S 687 | 14 | 7 | 5 | 9 | 2 | 31000 | 40000 | 0.003 | ||
S 688 | 16 | 8 | 4 | 9 | 2.381 | 29000 | 38000 | 0.0038 | ||
S 689 | 17 | 9 | 4 | 11 | 2 | 28000 | 36000 | 0.004 | ||
S 6800 | 19 | 10 | 5 | 9 | 2.381 | 26000 | 34000 | 0.005 | ||
S 6801 | 21 | 12 | 7 | 9 | 2.381 | 22000 | 30000 | 0.006 | ||
S 6802 | 24 | 15 | 5 | 12 | 2.381 | 20000 | 28000 | 0.007 | ||
S 6803 | 26 | 17 | 5 | 14 | 2.381 | 19000 | 26000 | 0.008 | ||
S 6804 | 32 | 20 | 5 | 15 | 3.5 | 17000 | 22000 | 0.009 | ||
S 6805 | 37 | 25 | 7 | 13 | 3.5 | 15000 | 19000 | 0.022 | ||
S 6806 | 42 | 30 | 7 | 15 | 3.175 | 13000 | 17000 | 0.026 | ||
S 6807 | 47 | 35 | 7 | 19 | 3.5 | 11000 | 15000 | 0.029 | ||
S 6808 | 52 | 40 | 7 | 22 | 3.5 | 9000 | 13000 | 0.033 | ||
S 6809 | 58 | 45 | 7 | 22 | 3.96 | 9500 | 12000 | 0.04 | ||
S 6810 | 65 | 50 | 7 | 27 | 3.969 | 9000 | 11000 | 0.052 | ||
S 6811 | 72 | 55 | 9 | 21 | 4.763 | 8500 | 10000 | 0.083 | ||
S 6812 | 78 | 60 | 10 | 23 | 4.763 | 7500 | 9000 | 0.106 | ||
S 6813 | 85 | 65 | 10 | 23 | 5.953 | 7000 | 8500 | 0.125 | ||
S 6814 | 90 | 75 | 10 | 22 | 5.953 | 6700 | 8000 | 0.135 | ||
S 6815 | 95 | 75 | 10 | 24 | 5.953 | 6300 | 7500 | 0.145 | ||
