2020 TOP SALE gypsum powder making machine , mtw trapezium grinding mill
- Category: Mine Mill >>>
- Supplier: Shanghai,Shibang,Machinery,Sales,Co.,Ltd.
Share on:
Product Overview
Description
2020 TOP SALE gypsum powder making machine , mtw trapezium grinding mill
Product Description
2020 TOP SALE gypsum powder making machine , mtw trapezium grinding mill information:
gypsum powder making machine is the latest powder mill innovatively designed through deep research by experts on the basis of long-term powder mill research and development experience. Its development absorbs the latest European powder grinding technology and concept, and combines the suggestions of 9158 customers of powder mill. This mill perfectly satisfies the production demands of the customers on 200-33μm (80-425Mesh) fine powder.
| Type: | Mineral Ore Powder Making mill |
| Input Size: | 15-50 mm |
| Processed Materials: | Limestone, calcite, barite, dolomite, potassium feldspar, marble, talcum, gypsum, kaolin, bentonite, medical stone, rock phosphate, iron ore, quartz, active carbon, coal, ect. |
| Applications: | Cement, coal, power plant desulfurization, metallurgy, chemical industry, non-metallic mineral, construction material, ceramics. |
2020 TOP SALE gypsum powder making machine , mtw trapezium grinding mill Working principle:
When entering grinding chamber, the raw materials are shoveled up by the shovels and grinded between the rollers and ring; the materials after grinding are brought into the separator along with the air from the blower, and the qualified fine powder became final products and come into the cyclone powder collector, the other unqualified powder fall down to be re-grinded. The circular air returns back to the blower that the above process will be repeated, and the remaining air enters the bag filter in order to protect the environment.
2020 TOP SALE gypsum powder making machine , mtw trapezium grinding mill flow chart:
2020 TOP SALE gypsum powder making machine , mtw trapezium grinding mill Feature:
1. Compared with other mills, its capacity increases by 10%-20% under the same power condition, and compression force of rollers to material improve 800-1200kgf under the force of high-pressure spring.
2. Size of final product can be 0.613mm (30mesh) –0.033mm (425mesh). Some can reach the fineness of 0.013mm (1000 mesh).
3. High Pressure Suspension Mill meets the requirement of national dust-dump standard.
4. The separator can be adjusted very easily.
5. The multi-class seals are adopted to keep the grinding equipment tightly closed.
2020 TOP SALE gypsum powder making machine , mtw trapezium grinding mill technical parameter:
| Model | MTW110 | MTW138 | MTW175 | MTW215 | |
| Major diameter of roller(mm) | 360×190 | 460×240 | 520×280 | 640×320 | |
| Inner diameter of roller (mm) | 1100×190 | 1380×240 | 1750×280 | 2150×320 | |
| Max.Feed Size(mm) | <30 | <35 | <40 | <50 | |
| Final size(mm) | 1.2-0.045, fineness can reach to 0.038 |
1.2-0.045, fineness can reach to 0.038 |
1.2-0.045, fineness can reach to 0.038 |
1.2-0.05, fineness can reach to 0.038 |
|
| Capacity(th) | 3-10 | 6-20 | 10-35 | 20-50 | |
| Main unit motor | Power(kw) | 55 | 90 | 160 | 280 |
| Centrifugal induced draft fan motor | Power(kw) | 55 | 110 | 200 | 315 |
| Classifier speed regulating motor(variable frequency motor) | Power(kw) | 7.5 | 22 | 37 | 90 |
| Magnetic Vibrating Feeder | Model | GZ2F | GZ3F | GZ4F | GZ5F |
| Power(kw) | 0.15 | 0.2 | 0.45 | 0.65 | |
