Автоматическое выравнивание UV LED блоки выдержки для паяльной маски фото припой сопротивления (1600061899853)

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description





Product Description


Product Application

KST-SA6457-TFH PISM Exposure machine is designed and developed by our own R&D Department. It is an ideal equipment for Solder mask multi colors ink. The machine with 8 CCD camera to align the film and the panel, Green ink bridge 3.0mil/ Solder mask opening1.5mil ( ≤1.0mil Can be customized).This machine is specialized in the mass production of various kinds of green, black, white etc.ink.

This machine is equipped LED light sources, greatly saving energy, cover different wavelengths, greatly meet the customer requirments one machine expose green, black, white etc.ink.. machine applied by the PC control system,Touch screen . With LED lamp imported from Korea, super power saving, and long service life, with 3 years warranty. High energy, greatly short down the exposure time, main white ink only takes3-5s,  Its reasonable design and stable performance improve the work efficiency and the quality of the products greatly.



Main Features

1) Simple structure in linear type ,easy in installation and maintation.

2) Automatic energy calibration and compensation, uniformity>90%

3) LED Technology, power savings, high efficiency, cost effective.

4) Built in temperature monitor module, alarming when LED over temperature.

5) High precision constant current driving power supply design, reducing the current impact of LED, greatly prolongs the LED service life.





Detailed Images


Machine Parts

Name: UV LED light source

Brand: SVC

Original: Korea

LED Technology, power savings, high efficiency, 3 years no need lamp replacement, cost effective.

Automatic energy calibration and compensation, uniformity above>90%



Solder mask opening

Green ink bridge 3.0mil/ Solder mask opening1.5mil ( ≤1.0mil Can be customized)
