23248CAW33C3 Сферический роликовый подшипник 23238 23240 23244 23248 CA CC MA 23248MB шахтный подшипник
- Category: Spherical Roller Bearings >>>
- Supplier: Shandong,Henggang,Bearing,Co.,Ltd.
Share on:
Product Overview
Description
| bearing brand | HGJX |
| bearing model | 23218 23220 23222 23224 23226 E1 K MB |
| precision | P0. P6. P5. P4. P2 |
| clearance | C3. C4 |
| stock | rich stock |
| sample | available |
| certificate | ISO9001:2000 |
| terms of payment | T/T, Western Union, Paypal |
Spherical roller bearing 23238 23240 23244 23248 23252 23256 23260 23264 23268 23272 CA CC MA MB E1 EAE4 CDE4 related model:
| Part Number | Size(mm) | Basic Load Ratings(Ibf) | Weight(KG) | Limiting Speed (min-1) | |
| Dynamic(Cr) | Static(Cor) | Grease | |||
| 23218CA/W33 | 90*160*52.4 | 495 | 585 | 4.82 | 2500 |
| 23220CA/W33 | 100*180*60.3 | 415 | 599 | 6.58 | 2100 |
| 23222CA/W33 | 110*200*69.8 | 502 | 742 | 9.66 | 1600 |
| 23224CA/W33 | 120*215*76 | 535 | 940 | 12 | 1500 |
| 23226CA/W33 | 130*230*80 | 670 | 1020 | 14 | 1300 |
| 23228CA/W33 | 140*250*88 | 910 | 1365 | 18.5 | 1200 |
| 23230CA/W33 | 150*270*96 | 850 | 1550 | 24 | 1100 |
| 23232CA/W33 | 160*290*104 | 1100 | 1760 | 30 | 1000 |
| 23234CA/W33 | 170*310*110 | 1070 | 1930 | 36.5 | 950 |
| 23236CA/W33 | 180*320*112 | 1160 | 2130 | 39 | 900 |
| 23238CA/W33 | 190*340*120 | 1290 | 2400 | 47.5 | 850 |
| 23240CA/W33 | 200*360*128 | 1360 | 2530 | 57 | 850 |
| 23244CA/W33 | 220*400*144 | 1720 | 3200 | 79.58 | 750 |
| 23248CA/W33 | 240*440*160 | 2080 | 3950 | 110 | 670 |
| 23252CA/W33 | 260*480*174 | 2800 | 4750 | 140 | 630 |
| 23256CA/W33 | 280*500*176 | 2580 | 5100 | 150 | 600 |
| 23260CA/W33 | 300*540*192 | 3300 | 5600 | 190 | 530 |
| 23264CA/W33 | 320*580*208 | 3900 | 6800 | 240 | 500 |
| 23268CA/W33 | 340*620*224 | 4660 | 8300 | 295 | 430 |
| 23272CA/W33 | 360*650*232 | 4650 | 8300 | 335 | 400 |
| 23276CA/W33 | 380*680*240 | 5060 | 9150 | 375 | 380 |
| 23280CA/W33 | 400*720*256 | 6150 | 11300 | 450 | 340 |
| 23284CA/W33 | 420*760*272 | 5610 | 11900 | 535 | 320 |
| 23288CA/W33 | 440*790*280 | 6730 | 12500 | 590 | 320 |
| 23292CA/W33 | 460*830*296 | 7350 | 13500 | 695 | 300 |
| 23296CA/W33 | 480*870*310 | 6750 | 15200 | 800 | 260 |
| 232/500CA/W33 | 500*920*336 | 8600 | 18600 | 985 | 280 |
| 232/530CA/W33 | 530*980*355 | 11100 | 20400 | 1200 | 220 |
| 232/560CA/W33 | 560*1030*365 | 11500 | 22000 | 1350 | 200 |
| 232/600CA/W33 | 600*1090*388 | 13100 | 25500 | 1600 | 190 |
| 232/670CA/W33 | 670*1220*438 | 15400 | 30500 | 2270 | 170 |
| 232/750CA/W33 | 750*1360*475 | 18700 | 36500 | 3050 | 150 |
More bearings we offer you: rodamientos fag spherical roller bearing 23238 23240 23244 23248 23252 23256 23260 23264 23268 23272 CA CC MA MB E1 EAE4 CDE4
1.Spherical Roller Bearing Information:
Roller bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads.
These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered.
All roller bearings are open, shielded, or sealed.
Sealed bearings are lubricated with oil or grease in the bearing factory, while open and shielded bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use.
The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan.
rodamientos fag spherical roller bearing 23238 23240 23244 23248 23252 23256 23260 23264 23268 23272 CA CC MA MB E1 EAE4 CDE
Exhibition & certification rodamientos fag spherical roller bearing 23238 23240 23244 23248 23252 23256 23260 23264 23268 23272 CA CC MA MB E1 EAE4 CDE4
Packaging & Shipping rodamientos fag spherical roller bearing 23238 23240 23244 23248 23252 23256 23260 23264 23268 23272 CA CC MA MB E1 EAE4
