61N 85550 10 ROTOR ASSY FOR YAMAHA HIDEA PARSUN SEATAN 2 STROKE 25HP 30HP OUTBOARD ENGINE MOTOR SPARE PARTS

Product Overview

Description

61N-85550-10 ROTOR ASSY FOR YAMAHA HIDEA PARSUN SEATAN 2 STROKE 25HP 30HP OUTBOARD ENGINE MOTOR SPARE PARTS



GENERAL SPECIFICATION

1, ROTOR ASSY FOR YAMAHA 2 STROKE 0HP OUTBOARD MOTOR

2, PARTS CODE 61N-85550-10

3, OEM QUALITY WITH COMPETATIVE PRICES.

4, 1 YEAR WARRANTY FOR AFTER SALES SERVICE



Our Goal

Build the YAMAPARTS service station, with full series of spare parts for your one stop shop, providing the highest quality spare parts for your outboard.



Our Competitive Advantage

• Full line of quality outboard and spare parts to meet your market needs.


• Interchangeable with OEM spare parts.


• Fast shipping and competitive shipping rates


• Live and professional customer service to answer all your questions.


• 100% satisfaction guarantee on all of our products.

Payment

We accept T/T, Western Union, PayPal.

30% deposit and 70% balance to be paid before delivery.



61N-85550-10 ROTOR ASSY YAMAPARTS IN BELLOW DIAGRAM



REF	PART NO.	DESCRIPTION	REMARK
1	61N-85550-10	ROTOR ASSY
	61T-85550-10	ROTOR ASSY
2	69P-85560-00	BASE ASSY
3	69P-85541-09	.COIL, CHARGE
4	61N-81313-09	.COIL, LIGHTING 1
5	61N-85543-09	.COIL, PULSER
6	61N-85543-19	.COIL, PULSER
7	6E9-81328-70	.CLAMP
8	97802-04006	.SCREW, PAN HEAD
9	6E9-85516-70	.GROMMET
10	69P-85561-00	.BASE, MAGNETO
11	97607-04112	.SCREW, PAN HEAD WITH WASHER
12	97607-06125	.SCREW, PAN HEAD WITH WASHER
13	61N-85537-00	.COVER
14	90280-05015	KEY, WOODRUFF
15	90179-16M05	NUT
16	90201-16M44	WASHER, PLATE
17	676-41611-00	RETAINER, MAGNETO BASE
18	676-41611-00	PLATE, BASE FRICTION
19	97880-05012	SCREW, PAN HEAD
20	92990-05600	WASHER, PLATE
21	689-41612-01	RETAINER, MAGNETO BASE
22	97880-06010	SCREW, PAN HEAD

WE HAVE FULL SERIES OF OUTBOARD MOTOR SPARE PARTS, PLEASE EMAIL US IF YOU HAVE ANY NEEDS, AND WELCOME TO JOIN OUR YAMAPARTS SERVICE STATION.
