Shibang machinary grinding mill to grinding bentonite in indonesia
- Category: Mine Mill >>>
- Supplier: Shanghai,Shibang,Machinery,Sales,Co.,Ltd.
Share on:
Product Overview
Description
Shibang machinary grinding mill to grinding bentonite in indonesia
Product Description
Name |
Shibang machinary grinding mill to grinding bentonite in indonesia |
Applicable material |
grinding mill to grinding bentonite is suitable in grinding Feldspar, calcite, talc, barite, fluorite, rare earth, marble, ceramic, bauxite, manganese ore, iron ore, copper, phosphorus ore, iron oxide red, zirconium English sand, slag, slag, clinker, activated carbon, dolomite, granite, pomegranate stone, iron oxide yellow, fly ash, bituminous coal, coking coal, lignite, Ling beautiful sand, chrome oxide green, gold, red mud, kaolin, coke, coal gangue, porcelain clay, cyanite, fluorite, bentonite, medical stone rhyolite, pyrophyllite, shale, sand stone, green muddy rock, Diego rocks, Greystone, gypsum, graphite, silicon carbide etc. |
Capacity(t/h) |
3-22 TPH |
Max Feeding |
35mm |
Final size |
1.6-0.045 fineness can reach to 0.038mm |
Model Number |
MTM100 MTM130 MTM160 |
Motor Type |
AC Motor |
Main unit motor powder |
37KW 75KW 132KW |
Color |
Iron Grey and can be changed upon customers' requirements |
Brand Name |
SBM |
Place of Origin |
Shanghai, China |
Design |
Independent patent design |
Certification |
ISO9001:2000, CE |
Warranty |
12 Months |
After Sales Service |
The whole time |
Production Lead time |
60-90 days |
Packaging |
Standard Exporting Packing, nude packing, container, or upon customers' requirement |
Other details |
If you need other details, please contact us |
The standard configuration of MTM Medium Speed Trapezium Mill consists of main unit, reducer, powder classifier, cyclone collectors, bag filter, blower, motor and pipes. The optional accessories incloude jaw crusher, elevator, feeder and control cabinet.
| Name | MTM100 | MTM130 | MTM160 | |
| Ring roll number(pcs) | 4 | 5 | 6 | |
| Major diameter of roller(mm) | Φ310X170 | Φ410X210 | Φ440X270 | |
| Inner diameter of roller(mm) | Φ950X170 | Φ1280X210 | Φ1600X270 | |
| Revolving Speed(rmin) | 130 | 103 | 82 | |
| Max feed size(mm) | <25 | <30 | <35 | |
| Final size(mm) | 1.6-0.045 fineness can reach to 0.038 | 1.6-0.045 fineness can reach to 0.038 | 1.6-0.045 fineness can reach to 0.038 | |
| Output(th) | 3-8 | 6-11 | 9-22 | |
| Complete physical size(mm) | 7100x5900x7900 | 9200x7250x9700 | 12550x5700x8355 | |
| Main unit motor | Model | Y225S-4 | Y280S-4 | Y315M-4 |
| Power(kw) | 37 | 75 | 132 | |
| Rotate speed(rmin) | 1480 | 1480 | 1480 | |
| Centrifugal induced draft fan motor | Model | Y225S-4 | Y280S-4 | Y315M-4 |
| Power(kw) | 37 | 75 | 132 | |
| Rotate speed(rmin) | 1480 | 1480 | 1480 | |
| Classifier speed regulating motor | Model | YCT200-4A | YCT200-4B | YCT250-4A |
| Power(kw) | 5.5 | 7.5 | 18.5 | |
| Rotate speed(rmin) | 125-1250 | 125-1250 | 132-1320 | |
| Elevator | Elevator model | TH210 | TH210 | TH315 |
| Motor model | Y100L2-4 | Y100L2-4 | Y112M-4 | |
| Power(kw) | 3 | 3 | 4 | |
| Rotate speed(rmin) | 1430 | 1430 | 1440 | |
| Jaw Crusher | Jaw Crusher Model | PE200x350 | PE250x400 | PE250x750 |
| Main unit motor | Y160M-6 | Y180L-6 | Y200L2-6 | |
| Power(kw) | 7.5 | 15 | 22 | |
| Rotate speed(rmin) | 970 | 970 | 970 | |
| Magnetic vibrating feeder | Main unit motor | GZ2F | GZ3F | GZ3F |
| Power(kw) | 0.15 | 0.2 | 0.2 | |
Shibang machinary grinding mill to grinding bentonite in indonesia Working principle
The entire cycle of events in the machine requires these steps: the speed reducer promotes the revolving of centering axis, there is a cinquefoil shelf connected on the top of the axis and the roller device is equipped on the shelf and forms a swing pivot. The roller device not only rotates around the centering axis but also revolves round the ring, and the roller rotates itself because of rubbing action. There are shovel blades equipped bottom of thecinquefoil shelf. When shovle blades rotate with rollers, they throw up the materials and send them into the space between rollers and ring and then form a material bed, produced by the rotating of rollers. The material is crushed by the centrifugal force.
MTM PULVERIZING Line
Customer profile
Certain building material Co., Ltd, Jiangsu
Quite influential enterprise in local air-entrapping brick industry
It successively purchase 2 sets of YGM4120 high pressure pulveriser and a suit of MTM160 midvelocity T-shape grinder from company
Production line condition
Site: Jiangsu
Daily running: 10 hours
Feedstock: lime
Finished product: 150-200 screen mesh finished product powder, used for fabrication of air-entrapping brick
Configuration: MTM160 complete equipment
Main Specifications
| Model | Max.feed size(mm) | Size of Finished Product(mm) | capacity(TPH) |
| MTM160 | 35 | 1.6-0.045 | 7-22 |
Customer’s comment
Previously used YGM4121 is very good. Owing to expansion of company’s production base, we subsequently replace MTM160 pulveriser, running of which is quite stable. Your company’s service team is very professional and highly efficient. The price of Shibang machinery is a little higher, but it is worthwhile!
---Mr. Jiang, general manager of this building material Co.,Ltd.
Company Information
1. More than 20 years professional experience
2. All products achieved ISO9001:2000, CE certificate
3. Have the most powerful and most professional team
4. Have professional technical staff
5. Modernized production workshop
6. Good after-sales service
Our Services
After we signed the purchase contract and have a certain reputation guarantee, we will contact the professional group that responsible for ship bookings, commodity inspection, commercial invoices, packing list, insurance policy and so on, in order to provide you the good goods trading services, until the product you purchased properly to your hands.
We will send a professional and high levels installation engineer team at the same time the product properly to the destination, in order to supply you a full range of products installation services. For some typical problems, our rigorous installed engineers also will do some certain installation debugging training, etc. Technological support SBM has been largely adopting new technologies, new techniques and high-tech equipments. And SBM also has strict and effective quality control system.
Packaging & Shipping
Ways of Packing:
1.Sand blasting, coat with high quality paint;
2.Product wrap by PP-Bubble
3.Load container, Spear Parts in wooden case.
Transportation:
1. By sea Freight;
2. MSK/MSC/APL/EMC/WANHAI/KLINE
3. We will remind you before boat arrival
FAQ
Q: Why we believe in Shanghai shibang company?
A:
1. More than 20 years experience.
2. SBM is the leading professional supplier of solution, equipments and service for crushing and grinding industry.
3. All products achieved ISO9001:2000 quality management certificate and EU CE certificate.
Q: Delivery time
A: The lead time is 10-30 days, Delivery time will vary depending on the type of the machine, shipping method selected and
part availability.
Q: Payment terms
A: Accepted Payment Type: T/T, L/C, Western Union, Cash
After sign the contract, pay the 10%-30% deposit of total purchase price and pay the full payment before delivery.
Q: what will you do if the machine is broken down?
A: The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when
the machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.
Q: What should i do if I want to get a best quotation?
A: If you want a suitable type for you ,please let us know your material and capacity.
