94702 00247 PLUG SPARK (BR8HS 10) FOR YAMAHA HIDEA PARSUN SEATAN 2 STROKE 25HP 30H OUTBOARD MOTOR CRANKCASE

Product Overview

Description

94702-00247 PLUG SPARK (BR8HS-10) FOR YAMAHA HIDEA PARSUN SEATAN 2 STROKE 25HP 30H OUTBOARD MOTOR CRANKCASE



GENERAL SPECIFICATION

1, PLUG SPARK (BR8HS-10) FOR YAMAHA 2 STROKE 25HP 30HP OUTBOARD MOTOR

2, PARTS CODE 94702-00247

3, OEM QUALITY WITH COMPETATIVE PRICES.

4, 1 YEAR WARRANTY FOR AFTER SALES SERVICE



Our Goal

Build the YAMAPARTS service station, with full series of spare parts for your one stop shop, providing the highest quality spare parts for your outboard.



Our Competitive Advantage

• Full line of quality outboard and spare parts to meet your market needs.


• Interchangeable with OEM spare parts.


• Fast shipping and competitive shipping rates


• Live and professional customer service to answer all your questions.


• 100% satisfaction guarantee on all of our products.

Payment

We accept T/T, Western Union, PayPal.

30% deposit and 70% balance to be paid before delivery.



94702-00247 PLUG SPARK (BR8HS-10) YAMAPARTS IN BELLOW DIAGRAM



REF	PART NO.	DESCRIPTION	REMARK
1	69P-W0090-00-1S	CRANK CYLINDER ASSY
	69S-W0090-00-1S	CRANK CYLINDER ASSY
2	69P-15100-00-1S	CRANKCASE ASSY
3	90119-08009	BOLT, WITH WASHER
4	90119-08M65	BOLT, WITH WASHER
5	93606-12019	PIN, DOWEL
6	689-15396-01-5B	HOUSING, OIL SEAL
7	93102-25008	OIL SEAL
8	93101-16001	OIL SEAL
9	93210-58M21	O-RING
10	97095-06022	BOLT
11	92995-06600	WASHER
12	6J8-11325-00	ANODE
13	6H3-11327-00-94	COVER, ANODE
14	6H3-11328-00	GROMMET, ANODE
15	97013-06016	BOLT
16	92903-06600	WASHER, PLATE
17	689-11325-00	ANODE
18	90151-06M02	SCREW, COUNTERSUNK
19	61N-11111-01-1S	HEAD, CYLINDER 1
20	676-11372-00	.NIPPLE, HOSE
21	61N-11181-A1	GASKET, CYLINDER HEAD 1
22	61N-11191-01-1S	COVER, CYLINDER HEAD 1
23	61N-11193-02	GASKET, HEAD COVER 1
24	90119-06MA2	BOLT, WITH WASHER
25	90119-08015	BOLT, WITH WASHER
26	6E5-12411-01	THERMOSTAT
27	90201-21567	WASHER, PLATE
28	655-12413-01-1S	COVER, THERMOSTAT
29	655-12414-00	GASKET, COVER
30	90119-06MA2	BOLT, WITH WASHER
31	6K8-41121-00-1S	INNER COVER,EXHAUST
32	6K8-41122-A1	GASKET, EXHAUST INNER COVER
33	61N-41123-00-1S	OUTER COVER, EXHAUST
34	676-11372-00	.NIPPLE, HOSE
35	90445-10M41	HOSE (L105)
36	6K8-41124-A1	GASKET, EXHAUST OUTER COVER
37	90119-06MA3	BOLT, WITH WASHER
38	90119-06MA4	BOLT, WITH WASHER
39	90119-06MA0	BOLT, WITH WASHER
40	90201-50306	WASHER, PLATE
41	689-45113-A1	GASKET, UPPER CASING
42	94702-00217	PLUG, SPARK (NGK B7HS-10)

WE HAVE FULL SERIES OF OUTBOARD MOTOR SPARE PARTS, PLEASE EMAIL US IF YOU HAVE ANY NEEDS, AND WELCOME TO JOIN OUR YAMAPARTS SERVICE STATION.
