China Manufacture Industrial Water Cooled Chilling Equipment Factory Price Mini Portable Water Cooling Chillers System
- Category: >>>
- Supplier: Suzhou Lesintor I/e Co. Ltd.
Share on (1600071502000):
Product Overview
Description
China Manufacture Industrial Water Cooled Chilling Equipment Factory Price Mini Portable Water Cooling Chillers System
Water Cooled Chiller | ||||||||||||||||||
Parameter/Model | 03WC | 05WC | 06WC | 08WC | 10WC | 20WC | 25WC | 30WC | ||||||||||
KW/hr | 9.59 | 15.91 | 19.18 | 24.85 | 31.83 | 67.14 | 81.53 | 99.19 | ||||||||||
Kcal | 8251 | 13690 | 16503 | 21370 | 27370 | 57748 | 70120 | 85303 | ||||||||||
Temperature Range | 5℃-room temperature(Below 0℃ Could be Customized) | |||||||||||||||||
Voltage | 3N-380V 50HZ | |||||||||||||||||
Power | KW | 2.575 | 4.50 | 5.25 | 6.75 | 9.00 | 17.20 | 20.95 | 26.00 | |||||||||
Control Method | Capillary Tube | Expansion Valve | ||||||||||||||||
Compressor | Type | Hermetic Scroll Type or Piston | ||||||||||||||||
Quanlity | 1 | 2 | 3 | |||||||||||||||
Power(KW) | 2.20 | 3.75 | 4.50 | 6.00 | 7.50 | 15.00 | 18.75 | 22.00 | ||||||||||
Refrigerant | R22 | |||||||||||||||||
Condenser | Form | Straight Pipe Type | ||||||||||||||||
Evaporator | Water Volume(M3/H) | 1.65 | 2.75 | 3.30 | 4.27 | 5.47 | 11.55 | 14.03 | 17.06 | |||||||||
Water Capacity(M3) | 0.05 | 0.06 | 0.06 | 0.15 | 0.15 | 0.30 | 0.38 | 0.38 | ||||||||||
Water Tank Capacity(L) | 45 | 50 | 60 | 140 | 145 | 245 | 270 | 300 | ||||||||||
Import and Export Caliber | DN25 | DN50 | DN65 | DN65 | ||||||||||||||
Pump | Power(KW) | 0.37 | 0.37 | 0.37 | 0.75 | 0.75 | 4.0. | 4.0 | 4.0 | |||||||||
Water Discharge(L/MIN) | 90 | 90 | 90 | 170 | 170 | 800 | 800 | 800 | ||||||||||
Water-lift(M) | 18 | 18 | 18 | 14 | 14 | 21 | 24 | 24 | ||||||||||
Dimension | L(MM) | 870 | 870 | 870 | 1300 | 1300 | 1750 | 1750 | 1800 | |||||||||
W(MM) | 550 | 550 | 550 | 680 | 680 | 760 | 760 | 800 | ||||||||||
H(MM) | 900 | 900 | 900 | 1300 | 1300 | 1500 | 1500 | 1500 | ||||||||||
Air Cooled Chiller | ||||||||||||||||||
Parameter/Model | 01AC | 02AC | 03AC | 05AC | 08AC | 20AC | 25AC | 30AC | ||||||||||
Cooling Capacity | KW/hr | 2.94 | 5.67 | 8.39 | 13.95 | 21.80 | 59.08 | 71.72 | 87.20 | |||||||||
Kcal | 2528 | 4872 | 7216 | 11990 | 18747 | 50805 | 61683 | 74992 | ||||||||||
Temperature Range | 5℃-room temperature(Below 0℃ Could be Customized) | |||||||||||||||||
Voltage | 1N-220V 50HZ | 3N-380V 50HZ | ||||||||||||||||
Power | KW | 1.27 | 2.02 | 2.85 | 4.86 | 7.65 | 18.80 | 22.75 | 28.50 | |||||||||
Control Method | Capillary Tube Type | Expansion Valve | ||||||||||||||||
Compressor | Type | Hermetic Scroll Type or Piston | ||||||||||||||||
Quanlity | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 3 | ||||||||||
Power(KW) | 0.75 | 1.50 | 2.20 | 3.75 | 6.00 | 15.00 | 18.75 | 22.00 | ||||||||||
Refrigerant | R22 | |||||||||||||||||
Fan | Air Volume | 1000 | 2000 | 3000 | 5000 | 8000 | 20000 | 25000 | 30000 | |||||||||
Size(MM) | 350 | 350 | 350 | 400 | 450 | 500 | 500 | 550 | ||||||||||
Quanlity | 1 | 1 | 2 | 2 | 2 | 4 | 4 | 4 | ||||||||||
Power | 0.14 | 0.14 | 0.17*2 | 0.23*2 | 0.43*2 | 0.55*4 | 0.55*4 | 0.55*4 | ||||||||||
Condenser | Form | Efficient Brass Sets Coorrugated Aluminum Fin | ||||||||||||||||
Evaporator | Water Volume(M3/H) | 0.51 | 0.97 | 1.44 | 2.40 | 3.75 | 10.16 | 12.34 | 15.20 | |||||||||
Water Capacity(M3) | 0.028 | 0.040 | 0.050 | 0.065 | 0.130 | 0.280 | 0.320 | 0.320 | ||||||||||
Water Tank Capacity(L) | 30 | 45 | 45 | 65 | 140 | 245 | 270 | 300 | ||||||||||
Inport and Export Caliber | DN20 | DN25 | DN25 | DN25 | DN40 | DN50 | DN65 | DN65 | ||||||||||
Pump | Water Discharge(L/MIN) | 90 | 90 | 90 | 90 | 170 | 800 | 800 | 800 | |||||||||
Water-lift(M) | 18 | 18 | 18 | 18 | 14 | 21 | 24 | 24 | ||||||||||
Power(KW) | 0.37 | 0.37 | 0.37 | 0.37 | 0.75 | 4.0 | 4.0 | 4.0 | ||||||||||
Dimension | L(MM) | 436 | 750 | 1040 | 1300 | 1500 | 2000 | 2000 | 2400 | |||||||||
W(MM) | 337 | 520 | 570 | 650 | 700 | 1100 | 1100 | 950 | ||||||||||
H(MM) | 753 | 800 | 1000 | 1100 | 1250 | 1780 | 1780 | 1780 | ||||||||||
Q: How to Guarantee The Quality ?
A: We have our factory.We are experts in our industry and have operated for more than 20 years.We
always adhere to the policy of"high quality, low price, all-round service".
Q: Can It Be Customized ?
A: Of course YES.We will according to your requirements for customized products carefully.And then
conduct in-depth analysis.Finally, we are committed to meeting your expectations for this customization.
Q: What About The Delivery Time ?
A: Usually,We will deliver the goods in two weeks.If we need customization,the delivery time will be about 20 days according to the actual situation.
Q: What About the Warranty ?
A: Within 1 year from the factory.If the parts are faulty or damaged (due to quality problems, except for worn parts),our company will provide these parts free of charge.
Q: What About The Terms Of Payment ?
A: 100% wire transfer,Signature of L / C Western Union or trade guarantee order recommendation before shipment.
always adhere to the policy of"high quality, low price, all-round service".
Q: Can It Be Customized ?
A: Of course YES.We will according to your requirements for customized products carefully.And then
conduct in-depth analysis.Finally, we are committed to meeting your expectations for this customization.
Q: What About The Delivery Time ?
A: Usually,We will deliver the goods in two weeks.If we need customization,the delivery time will be about 20 days according to the actual situation.
Q: What About the Warranty ?
A: Within 1 year from the factory.If the parts are faulty or damaged (due to quality problems, except for worn parts),our company will provide these parts free of charge.
Q: What About The Terms Of Payment ?
A: 100% wire transfer,Signature of L / C Western Union or trade guarantee order recommendation before shipment.
