Product Overview

Description




SINCR 1HP-90HP Solar Power AC Water Pump




system







Products Details







As a professional manufacturer of solar pump system solutions and solar pump inverters, SINCR provides practical, professional and reliable AC and DC solar pump systems for agricultural irrigation and industrial applications.
SINCR solar pump system consists mainly of solar panels, solar pump inverters and solar water pumps.
















































































































































































The Product Specification
Model No.3SP1-153SP2-244SP2-284SP5-25
Power0.5HP/0.37KW1HP/0.75KW2HP/1.5KW3HP/2.2KW
Water Head50-34m79-52m126-92m124-95m
Hourly Water Flow1-1.8m³1.5-2.5m³1.8-2.4m³3.6-5.4m³
Outlet Dia.3"3"4"4"
Recommended
MPP Voltage		250-350VDC250-350VDC250-350VDC500-700VDC
Model No.4SP8-244SP14-185SP10-15*5SP20-13
Power5.5HP/4KW7.5HP/5.5KW10HP/7.5KW12.5HP/9.2KW
Water Head118-79m88-49m144-123m112-75m
Hourly Water Flow6.6-10.2m³12-18m³8-12m³15-25m³
Outlet Dia.4"4"5"5"
Recommended
MPP Voltage		500-700VDC500-700VDC500-700VDC500-700VDC
Model No.5SP25-145SP30-166SP20-326SP60-16
Power15HP/11KW20HP/15KW30HP/22KW40HP/30KW
Water Head123-76m131-80m304-230m157-98m
Hourly Water Flow20-30m³25-35m³15-23m³54-72m³
Outlet Dia.5"5"6"6"
Recommended
MPP Voltage		500-700VDC500-700VDC500-700VDC500-700VDC
Model No.8SP77-138SP95-1710SP125-0910SP160-09
Power75HP/55KW100HP/75KW125HP/93KW150HP/110KW
Water Head195-160m213-166m195-150m195-162m
Hourly Water Flow60-84m³90-105m³110-140m³140-180m³
Outlet Dia.8"8"10"10"
Recommended
MPP Voltage		500-700VDC500-700VDC500-700VDC500-700VDC

Note: This is one of the specifications of each series of products. If you need a suitable head and water flow, please let us know the details.





The Actual Case


♦ Pakisitan 3KW solar agriculture irrigation system.
















































Location



 Sindh-Pakistan



Purpose



 Agriculture irrigation



Water source



 River. water depth 8-10m, 2m from river to tank.



Requiredments



 Pakistan is a large country with traditional agricultural production.Due to the shortage of elecricity,
 when agriculture irrigation requires water,it often loses power,which will have a great impact and
 loss on the cultivation of local farmers. In order to solve the actual pumpong difficulties,SINCREA
 solar pump irrigation system was introduced to meet the needs of agriculture irrigation.



Solution



Solar Water pump



 3KW AISI304 submersible pump,3P 380V


 Rated water flow:20 m³/h; Rated lift head:10m



Solar panel



 4.8KW,15pcs 320W Mono solar panel in series.



Solar pump inverter



 SINCREA,Model:SV500-004-4TB


 4KW Solar pump inverter,3P 380V.



Mounting bracket



 Ground fixed Q235 hot galvanizing stell mounting bracket.



Accessoies



 DC/AC cables, MC4 connector, water level sensor, DC/AC multi-meter, installation tool, etc.



Benefits



Adopting SINCREA 3kw solar pump system,the 4.8kw solar panel drive the 3kw pump by the 4kw
solar pump inverter.The system pump water from the 8m depth river to the tank,and then flows to
each farmland through the channel,working 6-8 hours a day,100-150 cubic meters of water can be
pumped for farmland irrigation,solving the water shortage due to power outage and water shortage,
fully automatic operation,and no manual operation.









Customer's feedback


feedback of whole store.jpgfeedback of solar inverter.jpg





Company Information


Shenzhen SINCREA Electrical Technology Co., Ltd. is a professional enterprise on frequency inverter technology development and application . Our company is located in Shenzhen, which is the best innovation city in China. We integrate research, production and sales, with independent intellectual property rights and proprietary trademarks. Take cohesion, innovation and competitiveness as our core, advanced technology, excellent management concept and high-quality products make us popular with our customers.



.jpg





Enterprise Culture solar water pump drive


♦ Vision: to become the leading industrial automation product solutions supplier.


♦ Mission: use advanced technology to promote industry civilization.


♦ Values: customer success, pursuit excellence, faith to the letter, solidarity and cooperation.





FAQ


Q1.what's your payment terms?


A:We accept  L/C,T/T,Western Union,Money Gram,CNY.


Q2.How long does it take to deliver the goods?


A:If the stocks, usually sized orders are sent out within 14 working days.


Q3.How do you usually make delivery?How long?.


A:Courier delivery ( FedEx,DHL,UPS,EMS,TNT) takes 3-6 days depending on your destination.


Q4.How do you ship the products?


A:Sea Freight & Air Mail & Bulk Air Freight.


Q5.Do you support the oem business?


A:Yes,Including LOGO, outer packaging, graphics and user manual.Please email us that what you want to print.


Q6.How to choose right Solar submersible pump?


A:Please tell us your requirements and questions, we will answer you as soon as possible.And we will consult our engineers and adjust the right equipment for you.
