Smart Watch Sport IP67 Waterproof pedometers Message Reminder Men Smart Watch
Product parameters | ||
Model | FKLS11 | |
Colour | Black/silver | |
Product Dimension | 265mm(L)X 47mm(W)X 13.5mm(H) | |
Net Weight | 55±1 g | |
Chipset | RTL8762C | |
Chip platform | PHY | |
Dominant frequency | 40Mhz | |
Framework | ARM | |
Nuclear number | single-care | |
Main memory | rom 512KB sram 160KB | |
falsh | 128M | |
Auxiliary chips | G-sensor STK8321 | |
Operation method | Touch | |
Charge mode | Magneic absorpion charaina wire | |
Charge specification | Output:5V/300mA | |
Waterproofing grade | IP67 | |
Bluetooth Version | BLE5.0 | |
Display screen | Touch:Capacitive touch | |
Material:OGS | ||
Type:1.28inch IPS color screen | ||
Resolution:240*240 | ||
Battery | Polymer lithium ion | |
Battery capacity:300mAh | ||
Charging time: about 2H | ||
Material | "Zinc alloy case | |
Pan material | ABS+PCmaterial | |
Strap material | liquid silicone strap | |
Trumpet | none | |
Mike | none | |
Motor | Built-in vibration reminder 820 bonding wire | |
Heart rate chip | EM 7028 | |
Sensor | Optical heart rate sensor, 3D acceleration sensor | |
Prodoct Features | ||
The main function | Step gauge | Turn on the step count, which represents steps, exercise time, mileage and calories burned |
Movement time | Start the movement function of the bracelet to record the total movement time | |
Movement patterns | A total of 9, running, hiking, cycling, mountaineering, basketball, rope skipping, table tennis, badminton, football | |
Movement range | Start the movement function of the bracelet to calculate the total distance of movement | |
Calorie consumption | The bracelet calculates the calories burned based on different exercise patterns, exercise time, and exercise mileage | |
Real-time heart rate measurement | The bracelet or APP terminal activates the heart rate function, which can measure the current heart rate and display the measurement results (wear the bracelet when measuring the heart rate). | |
Blood pressure measurement | none | |
Blood oxygen measurement | none | |
Sleep patterns | Record the duration of sleep and the duration of deep and light sleep | |
Sedentary remind | The APP sets the time interval for the sedentary reminder, and the bracelet will display the reminder icon and vibration reminder after the arrival time | |
Phone calls reminding | Incoming calls can be answered/hung up at the end of the ring | |
Being pushed | A total of 22, /Instagram/YouTube/Messenger/Gmail/Snapchat/Facebook/Twitter/WhatsApp/Pinterest/Hangouts/LinkedIn/Skype/Tumblr/Viber/Line/Google+/Flickr/VK/Kakao Talk | |
Dial | The end of the bracelet can be dialed freely | |
The contact | none | |
Lift the wrist bright screen | After the APP opens the wrist lifting bright screen switch, the screen can be lit by turning the wrist or raising the hand when the bracelet is in standby mode | |
DO Not disturb | The end of the bracelet can be enabled in the do not disturb mode. When the do not disturb mode, there is no message reminder or call reminder | |
Looking for bracelets | The bracelet connects to the status of the APP, and the APP terminal enters into the search bracelet. The bracelet will display the reminder icon and vibration reminderr | |
Looking for mobile phone | When the bracelet connects to the APP status, the end of the bracelet selects the phone to look for, and the APP end will sound the prompt sound | |
Remote control picture | When the APP and the bracelet enter the camera interface, you can start the phone camera and click to take a photo | |
Bluetooth phone | none | |
The bluetooth music | none | |
secdnd chronograph | The stop watch function is entered at the end of the bracelet to start/stop the timer | |
alarm clock | The APP sets the alarm time, and the bracelet will display alarm alarm pictures and vibration reminders after the time is reached | |
Device reset | The end of the bracelet can reset the device and clear all the use records of the bracelet | |
Equipment solutions to | The APP terminal can release the currently bound bracelet device, and the bracelet can be re-bound after being unbound | |
Bracelet bluetooth | The bracelet end can view the connection status of 2 bluetooth | |
Vibrate setting | none | |
Multiple dial switching | The bracelet long press the main interface to switch different dial | |
brightness | The end of the bracelet can adjust the display brightness of the bracelet | |
volume | none | |
weather | The end of the bracelet can check the current regional weather conditions | |
APP support language | Chinese/English/Italian/Russian/Spanish/Portuguese/German/French/Czech/Japanese/Polish/Spanish /Korean | |
Bracelet support language | Chinese/English/Italian/Russian/Spanish/Portuguese/German/French/Czech/Japanese/Polish/Spanish /Korean | |
Bracelet push language | Chinese/English/Italian/Russian/Spanish/Portuguese/German/French/Czech/Japanese/Polish/Spanish /Korean | |
Support phone system | Android 5.0 or above; IOS9.0 and above; Support bluetooth | |
APP/APK download![]() |
Mobile phone scan bracelet download qr code download and install Tfit APP mobile APP store search Tfit APP download and install (APP download qr code is attached to the right) | |
package instruction | ||
Manner of packing | 50/CTN | |
Box size | 145*104*30 (MM) | |
Box Suttle | 80±1 (g) | |
Single package net weight (including packing box and accessories) | 153±2 (g) | |
Packing carton size | 53.5*16*32(CM) | |
Packing carton size | 352±2 (g) | |
Net Weight of cartons | 8.0±0.5 (kg) |
