disco amplifier stage amplifier pro P3000

Product Overview

Description

MODEL                     P3000
Stereo power  8Ω      500W
1KHz0.1%THD  4Ω       750W
             2Ω       2100W
Bridge mono Power  8Ω  1500W
1KHz0.1%THD  4Ω        1500W
Signal to noise        105dB
Slew Rate              80V/μS
Damping Factor         500:1
Frequency response     +/-0.1dB,20Hz+20kHz
THD                    ≤0.01%Rated Power@8Ω1kHz
IMD                    ≤0.01%Rated Power@8Ω
Input sensitivity      0.775V,1.0V.1.55V
Input impedance        10K/20K ohurs, unbalanced or balances
Imput CMRR             ≤-75dB
Cross talk             ≤-70dB
LEP indicator           Signal,Protect,Dctive,Clip/Limiting
Main power supply       FUSE:T20A
Supply power          1400W
Net Weight              23kg
Dimension(WXDXH)        483×480×143(mm)
