Hot Sale CE/ISO/SGS Approved Bottom Grain Silo Grain Steel Storage Silo
- Category: >>>
- Supplier: Jiangsu Liangyou Zhengda Co. Ltd.
Share on (1600077433708):
Product Overview
Description
Hot Sale CE/ISO/SGS Approved Bottom Grain Silo Grain Steel Storage Silo
Introduction to screw silo:
Made of high quality hot dip galvanized steel sheet (galvanized specification can be: 275g/, 350g/, 450g/). Processing and production units are the latest technology units with strong rigidity, high precision. The diameter range of the screw bin can range from 4m to 22m, the height of the straight barrel section can range from 2m to 20m, and the storage volume can range from 40m3 to 8000m3.
The interior of the silo can be configured with temperature measuring system, ventilation system, material level system and circulation fumigation system according to customer requirements.
Silos can be divided into: corn steel silos, soybean steel silos, wheat steel silos, barley steel silos, sorghum steel silos, soybean meal steel silos, sawdust steel silos, biomass pellet steel silos; At the same time, our company can customize the production of flour steel silos, cement steel silos, building materials steel silos;
According to the form of conical bottom, silos can be divided into: concrete flat bottom steel silos, concrete cone bottom steel silos, steel structure support silos (single silo capacity should be less than 1500T);
Features 1. High precision
Our grain silo has international advanced equipment and technology guarantees.
2. High automation
Our grain silo can achieve high automation and mechanisation, high productivity, labor-saving.
3. Wide storage
Our grain silo has wide storage. Capacity of single silo up to 15,000 tons, complete function, meet requirement of various customers.
4. Easy maintenance
Our grain silo, the standard, interchangeable and universal galvanized steel plates and accessories are convenient for maintenance, easy upgrading of capacity or silo move.
5. Less investment
20-30% less costs over steel bar concrete silos, greatly saving investment.
Project introduction:
This project is a 4-3000t cement storage project in the building materials industry. The process features are as follows:
1. The main materials in the steel silo are: cement, the silo type is a spiral silo. the diameter is ¢14m. The height of the straight section is 16m, and the foundation form is a concrete flat-bottomed foundation;
2. Main process flow: Discharge -- storage (air chute, fluidized bed) -- silo exit;
(1) The unloading section is double-sided unloading, and the unloading grid screen is the truck load-bearing model;
(2) The storage section is 4-3000t cement screw silo, and the silo input is 50TPH;
3. Features of the engineering process design:
(1) Adopt air chute type silo input;
(2) The mode of fluidized bed silo output is adopted;
(3) The base of silo bottom is designed in the form of concrete flat bottom.
4. Other instructions:
For different projects, different customer requirements, different processes, the following is the specific engineering options:
(1) Pneumatic conveying system is optional for the feeding system (applicable to small silo and slow feeding speed)
(2) Pneumatic conveying system can also be used for the discharging system;
(3) welding bin can be selected for small bin;
(4) Large cone angle can be selected for the mode of silo exit (suitable for small silos);
(5) Cement silo can be only chosen screw bin or welded bin.
Advantages
1. We have an excellent team with more than 20 years' experience in silo construction.
2. As one of the largest silo manufacturing company, we have introduced over 20 sets of processing units, and production capacity reaches 1 million tons per year.
3. FDSP provides a turn-key project from consultation, design, civil work, production, sales to service.
4. Hot galvanized steel plates are used for silo body, and galvanized steel is also used for silo roof batten, hood, handrail, hole for temperature-measurement, manhole and ladder to ensure long service life.
About us
Jiangsu Liangyou Zhengda Co., Ltd is a professional enterprise engaged in steel silo equipment and storage engineering technology research, development, design, manufacturing and related products sales & service. Steel silo engineering could be applied in: food industry, feed industry, oil industry, building materials industry, brewing industry and port industry. FDSP is specialized in design, manufacture, and installation for both domestic and foreign helix silo and bolt silo project.
The certificates and honors:
Our products have passed the SGS,ISO9001:2008,CE certifications.Moreover,we own several patents,such as "utility model patents certificate"and "high-tech products certificate",etc.Our goods exported to many countries such as,Egypt,Germany,Korea,Thailand etc. and won the good reputation by the premium quality and superior service.
