Туннельная морозильная камера IQF/замораживание блоков
- Category: Industrial Freezer >>>
- Supplier: Nantong Sinrofreeze Equipment Co. Ltd.
Share on (1600077552865):
Product Overview
Description
Product Description
IQF tunnel freezer is a simple structure, highly efficient freezing equipment. There are stainless steel solid belt tunnel freezer and mesh belt tunnel freezer. It is effective in freezing seafood, poultry, vegetable, fruits, pastry, diary products, etc.
Freezing capacity is between 200kg-2000kg/h.Main features:
1. Simple structure, easy operation and long lasting.
2. Stainless steel insulation panel is filled with PU foam. All inside spare parts are SUS304. Easy for cleaning and meet HACCP requirement.
3. Adopt imported SS mesh belt. Strong and smooth.
4. Thermal wave blowing technology is adopted. Effective in freezing.
5. Single belt and double belt are available.
6. Water defrosting which ensure hygienic standard.
7. Stepless speed adjustment by inventer. Freezing time can be adjusted.
Freezing capacity is between 200kg-2000kg/h.Main features:
1. Simple structure, easy operation and long lasting.
2. Stainless steel insulation panel is filled with PU foam. All inside spare parts are SUS304. Easy for cleaning and meet HACCP requirement.
3. Adopt imported SS mesh belt. Strong and smooth.
4. Thermal wave blowing technology is adopted. Effective in freezing.
5. Single belt and double belt are available.
6. Water defrosting which ensure hygienic standard.
7. Stepless speed adjustment by inventer. Freezing time can be adjusted.
Structure drawing
1. Inlet frame
2. Insulation panel
3. Evaporator
4. Fan
5. Air deflector
6. Drive reducer
7. Inside passage
8. SS supportor
9. Outlet frame
10. Electric control panel
11. Mesh belt
3. Evaporator
4. Fan
5. Air deflector
6. Drive reducer
7. Inside passage
8. SS supportor
9. Outlet frame
10. Electric control panel
11. Mesh belt
Structure drawing
1. Inlet frame
2. Insulation panel
3. Evaporator
4. Outlet frame
5. Centrifugal fan
6. Drive reducer
7. Air deflector
8. Electric control panel
9. Inside passage
10. Mesh belt
3. Evaporator
4. Outlet frame
5. Centrifugal fan
6. Drive reducer
7. Air deflector
8. Electric control panel
9. Inside passage
10. Mesh belt
Detailed Images
Size Information
Technical specifications
Model | TPD2-200 | TPD2-500 | TPD2-750 | TPD2-1000 |
Freezing capacity(kg/h) | 200 | 500 | 750 | 1000 |
Refrigeration capacity(kw) | 45 | 90 | 135 | 180 |
Motor power(kw) | 17 | 32 | 47 | 62 |
Refrigerant | R717/R22/R404A | R717/R22/R404A | R717/R22/R404A | R717/R22/R404A |
Overall dimension | 5.12×4.4×3.05m | 8×4.4×3.05m | 10.88×4.4×3.05m | 13.76×4.4×3.05m |
Related Products
Packing&Shipping
Company Introduction
Nantong Sinrofreeze Equipment Co., Ltd. was established in 2005. SINROFREEZE is a company engaged in designing, manufacturing, selling, maintaining and assembling of food freezing equipments and complete sets of refrigeration units. SINROFREEZE provides products and after-sell service to different application customers include seafood, meat and poultry, pastry, diary foods, fruits and vegetable and refrigeration field.
FAQ
Q1. When can I get the price ?
A1: We usually offer the quotation within 1-2 work days after receiving your detailed inquiry.
Please provide detailed requirements like the capacity, freezing product, product size&weight, inlet &outlet temperatures,
refrigerant and other special requirements if any.
Q2. What is the Trade Term?
A2: We accept Ex-work factory , FOB Shanghai, CNF or CIF, as your requirement.
Q3. How long is the production time?
A3: 60days after receiving down payment or Letter of credit.
Q4 .What is the Payment term?
A4: By 100% T/T before shipment or By L/C at sight.
Q5. What are your terms of packing?
A5: Packing: export worthy package suitable for container transportation.
Q6. Do you test all your goods before delivery?
A6: Yes, we have 100% test before delivery.
Q7: Where is your factory located?
A7: Our factory is located in Nantong, Jiangsu province.
Q8: What is your warranty?
A8: Warranty: 12months after commercial running.
Q9: Can you arrange thirty party pre-shipment inspection?
A9: Pre-shipment inspection: Supplier’s pre-shipment inspection is Final; pre-shipment inspection by third Party on buyers cost.
Q10: Can we do our OEM logo?
A10: Yes, for the products with drawing supplied by you, we of course apply your logo.
