Product Overview
Description
WG3526 wifi router with best range for United states
Warm Tips:
For different carriers in different countries have different bands and frequencies. If you don’t know which band was used in your country ,you can reference below information of band.After place order ,please kindly remind us the band you need to compatible.if you have question about the Band of the 4G please feel free contact with us,we will give advice.
SDF 3526 is equipped with a single Mini PCI-E modem slot which allows modem installation without additional hardware.
When installing a M.2 form modem into a Mini PCI-E modem slot, a Mini PCI-E to M.2 Key B adapter MUST be used (with or without optional SIM Card slot).
Refer to the steps at the bottom of this listing for instructions on installing a Mini PCI-E and M.2 modem.
Mini PCI-E Modems:
- Sierra Wireless CAT6 MC7455 (Multi-Carrier) 1
- Sierra Wireless CAT3 MC7354 (Multi-Carrier)
- Sierra Wireless CAT3 MC7700 (AT&T only)
- Sierra Wireless CAT3 MC7750 (Verizon only)
- Quectel CAT6 EP06-A (Multi-Carrier)
- Quectel CAT4 EC25-AF (Multi-Carrier, includes T-Mobile Band 71, and AT&T FirstNet Band 14)
M.2 Modems:
- Sierra Wireless CAT12 EM7565 (Multi-Carrier)
- Sierra Wireless CAT12 EM7511 (Multi-Carrier, includes AT&T FirstNet Band 14).
- Quectel CAT12 EM12-G (Multi-Carrier)
- Quectel CAT6 EM06-A (Multi-Carrier)
Specification:
|
Hardware |
|
|
Main Chipset |
MT7621/Dual Core/880Mhz |
|
RAM |
DDR3 RAM 512MB (MAX512MB) |
|
FLASH |
SPI FLASH 16MB (MAX32MB) |
|
Protocol Standard |
IEEE 802.11ac,IEEE 802.11a IEEE 802.11n,IEEE 802.11g,IEEE 802.11b; |
|
Wireless Rate |
5G : 900Mbps 2.4G: 300Mbps |
|
Work Frequency |
2.4GHz/5.8GHz |
|
Antenna |
4 * 5dBi high gain antenna or 6 external antenna (Adding 3G or 4G module) |
|
Interface |
1*10/100M/1000M WAN Port, Auto MDI/MDIX 1*USB 3.0 port 1*Mini-PCIE slot 1*SATA port 1 SIM card slot |
|
LED |
PWR.SYS.USB.2G.5G.WAN, LAN1-4 |
|
Button |
1*RESET |
|
Power consumption |
< 24W |
|
Adapter |
DC 12V 2A |
|
Others |
|
|
Work Environments |
Operating Temperature:-10℃ ~ 60℃; Operating Humidity:10%~90% non-condensing |
|
Authentication |
FCC, CE, ROHS |
