YPG nozzle tyoe pressure Detergent powder coconut milk spray dryer manufacturer
- Category: >>>
- Supplier: Changzhou Yinuo Drying Engineering Co. ltd.
Share on (1600083403865):
Product Overview
Description
General description of Nozzle jet spray dryer:
Spray dryer is suitable for solution, suspension, slurry, paste material, etc. Liquid material is atomized to small fog drops. And fog drops contact with hot air directly in the drying tower. Moisture content is evaporated instantly. So spray dryer features high efficiency, high mass transfer area, and short drying time, in general it is 5~30 seconds. Operating temperature can be adjusted according to actual situation, in general inlet air temperature is 150~500°C. And its automation control degree is control, environment solution environment can be solved.
Technical parameters of Nozzle jet spray dryer:
|
Model Item |
YPG-25 |
YPG-50 |
YPG-100 |
YPG-150 |
YPG-200 |
YPG-300 |
YPG-500 |
YPG-1000~2000 |
||
|
Water evaporation(kg/h) |
25 |
50 |
100 |
150 |
200 |
300 |
500 |
According to actual situation |
||
|
Diaphragm pump |
Power (Kw) |
0.35 |
4 |
7.5 |
11 |
15 |
22 |
30 |
||
|
Pressure (Mpa) |
It can be regulated from 0.6-5. In general, it is 1-3 |
According to actual situation |
||||||||
|
Heating source |
Electricity |
Electricity + steam |
Hot air furnace |
|||||||
|
Diameter of tower (mm) |
1300 |
1800 |
2400 |
2600 |
2800 |
3200 |
3800 |
According to actual situation |
||
Other Application of Nozzle jet spray dryer:
Foodstuff industry: Amino acid and similar substance, flavoring, protein, starch, dairy products, instant coffee, fish powder, meat powder, tomato paste and so on.
Pharmaceutical Industry: Chinese patent medicine, agrochemical, antibiotics, medical drinking agent and so on.
Chemical industry: Organic catalyst, resin, synthetic washing powder, thiamin, dyestuff, intermediate of dyestuff, intermediate of dyestuff, white carbon black, graphite, ammonium phosphate and so on.
Ceramic industry: Magnesium oxide, kaolin, metallic oxide, dolomite and so on.
Typical application
Foodstuff Amino acid, vitamin, egg powder, bone powder, flavouring, protein, milk powder, blood powder, soy sauce powder, coffee, tea powder, glucose, pentadiene carboxylic acid, pectin, flavours, vegetable juice, yeast, starch, etc.
Ceramic Alumina, zirconia, magnesium oxide, titania, pottery clay, china clay, all kinds of magnetic porcelain and metal-oxides, etc.
Chemical Aluminium polychlorid, disperse dyes, reactive dyes, organic catalyzer, white carbon black, washing powder, zinc sulfate, silica, sodium metasilicate, potassium fluoride, calcium carbonate, potassium sulfate, ingotganic catalyzer and all kinds of waste liquid, etc.
