Taken the application area: oil, mining, steel mills, power plants and other industries material conveying equipment or wear-resisting material on the surface of the liquid flowing through a pipe. *Taken the product characteristic: good abrasion resistance;The mohs hardness can reach 9.0.
Related Products
Matters needing attention for transportation and installation of ceramic pipe 1. The ceramic composite pipe has high hardness and good toughness, but it should be put gently in the process of transportation and installation to avoid serious collision, especially to avoid direct contact with metal instruments or impact on the ceramic layer on the end surface. 2. The yunfeng bending pipe is installed with directivity. When the bending pipe is installed, the direction indicated by the arrow on the surface of the bending pipe should be consistent with the flow direction of the conveying medium. 3. When installing the pipe, the pipe should be aligned with the center line and level should be adjusted to make sure that both ends meet accurately.The displacement of both ends should be controlled within 1.0mm. 4. When the flexible pipe joint is used to connect and install the pipe, the inserted lengths of both ends of the flexible pipe joint shall be adjusted symmetrically.Since the thermal expansion coefficient of the composite pipe is about 1/3 of that of steel, the expansion clearance can be reduced by 3-5mm. 5. When using flange connection, the flange end shall be flush with the end of the composite pipe. 6. Due to the excellent welding performance of the composite pipe, the pipe connection can be conducted by welding. However, when welding, 45o-60o "V" type slope Angle is 2-4mm and gap is 0.8-1.2mm.
Packing&Shipping
Packaging
Size
1200 (L) * 1000 (W) * 800 (D)
Weight
≤0.5T
Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Packaging
Size
1200(L) * 1000 (W) * 800 (H)
Weight
≤1.2 T
Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
After Sales Service
We can provide pre-sale,sale and after-sales service 1.ISO9001:2015 ISO14001-2015 2.Reply your inquiry in 24 working hours. 3. Experienced staffs answer all your questions in time. 4. Customized design is available. 5. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff. 6. Special discount and protection of sales are provided to our distributor. 7. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. 8.Full technical support:we will provide the foundation drawings of the machine and installation support.
Company Introduction
FAQ
Q: Are you trading company or manufacturer ? A: We are factory.
Q: How long is your delivery time? A: Generally it is 15 days if the mould sizes are in stock. or it is 25 days if the mould sizes are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the stock sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ? A: For new customers, 100% T/T in advance. For regular customers, 30% T/T in advance ,balance after received the B/L copy
If you have another question, pls feel free to contact us as below.
