Low price manual digital Coil counting winding machine
Product Description
This series of hand-cranked automatic wire-arranging machines adopt hand-cranked gear transmission, pointer or electronic counting, and mechanically control automatic wire-arranging. It can be used to wind various small coils with fewer turns and requiring automatic wiring.
Technical parameter:
Applicable cable diameter: 0.06-0.60mm
Row coil diameter: 12-150mm
Row coil width: 6-110mm
Counting range: 0-2499 circles
Transmission speed ratio: fast 1:6 (wire diameter 0.06mm-0.3mm);
Slow speed 1:1.5 (wire diameter 0.3mm-0.6mm) two gears,
The factory setting of the machine is slow.
*Pay-off stand shaft diameter 10mm
*Bobbin width 85mm
*Pay-off reel diameter 130mm
*Take-up shaft diameter 10mm
*Volume: 510mm*340mm*330mm
*Weight (net weight) 26 kg
Details Images
Mechanical principle:
1. The hand-cranked electric counting winding machine is driven by the main gear of the crank handle to drive the main shaft,and the counter is counted by the drive of the main gear without head gear. 10 revolutions, that is, the number of counter letters is 1 revolution.
2. The machine is hand-cranked and can be used for both electric and electric. Remove the handle when electric, allowing the maximum speed of the spindle of the winding machine to be 2000 rpm.
3. Add a little oil to the main oil hole normally.
Instructions:
1. The machine should be placed on a sturdy workbench with a wood board and three holes on the machine floor for fixing and mounting between the machine and the workbench.
2. When in use, use the left hand to move the counter reset lever to reset to 00000. It is required that the counter reset the
lever plate twice, so that the counting gears are all reset. (Otherwise, the gear slip count may be inaccurate) before
operation can be started. It can be reset to 0 after the operation. It is strictly forbidden to reset to 0 during operation.
1. The hand-cranked electric counting winding machine is driven by the main gear of the crank handle to drive the main shaft,and the counter is counted by the drive of the main gear without head gear. 10 revolutions, that is, the number of counter letters is 1 revolution.
2. The machine is hand-cranked and can be used for both electric and electric. Remove the handle when electric, allowing the maximum speed of the spindle of the winding machine to be 2000 rpm.
3. Add a little oil to the main oil hole normally.
Instructions:
1. The machine should be placed on a sturdy workbench with a wood board and three holes on the machine floor for fixing and mounting between the machine and the workbench.
2. When in use, use the left hand to move the counter reset lever to reset to 00000. It is required that the counter reset the
lever plate twice, so that the counting gears are all reset. (Otherwise, the gear slip count may be inaccurate) before
operation can be started. It can be reset to 0 after the operation. It is strictly forbidden to reset to 0 during operation.
NZ-5
NZ-7
FY -- 130 counting range 0 -- 9999.9 laps, counting error <0.1 laps.
Size: 115 * 115 * 185 mm
Shaft diameter: 10mm shaft length: 140mm
Size: 115 * 115 * 185 mm
Shaft diameter: 10mm shaft length: 140mm
This winding machine adopts hand drive, two-block speed, electronic counting display, counting accuracy, flexible operation,
stable performance, clear display, easy to use with power off data protection function.
