HaizhiLi Handling Equipment High quality foldable lift platform hand pallet stacker
- Category: >>>
- Supplier: Haizhili (Jingshan) Machine Technology Co. Ltd.
Share on (1600087182562):
Product Overview
Description
Product catalog
Details Images
Model | CTD.10/16 | CTD.10/20 | CTD.10/25 | CTD.10/30 | CTD.10/35 | CTD.10/40 | |||||
Load weight(kg) | 1000kg | ||||||||||
Max. lifting height(mm) | 1600mm | 2000mm | 2500mm | 3000mm | 3500mm | 4000mm | |||||
Min. lifting height(mm) | ≤90 | ||||||||||
Vehicle closing height(mm) | 2060 | 1550 | 1800 | 2050 | 2300 | 2550 | |||||
Maximum height of vehicle(mm) | 2060 | 2530 | 3030 | 3530 | 4030 | 4530 | |||||
Fork form | Movable Type or Fixed Type | ||||||||||
Maximum outer width of fork(mm) | 680 SIZE CAN BE CUSTOMIZED | ||||||||||
Fork Length(mm) | 1000 | ||||||||||
Load centre distance(mm) | 500 | ||||||||||
Long(mm) | 1740 | ||||||||||
Width(mm) | 780 | ||||||||||
Frame Structure | single frame | Dural frame | |||||||||
Min. turning radius(mm) | 1430 | ||||||||||
Battery specifications(V/W) | DC12V/1.6 | ||||||||||
Storage Battery(V/Ah) | 12/120 | ||||||||||
Battery working time(H) | 4 | ||||||||||
Charger specifications(V/A) | input 220V/50HZ, output12V/15A Can be equipped with charging adapter | ||||||||||
net weight(kg) | 310 | 354 | 368 | 382 | 396 | 410 | |||||
Model | CTD.15/16 | CTD.15/20 | CTD.15/25 | CTD.15/30 | CTD.15/35 | CTD.15/40 | |||||
Load weight(kg) | 1500kg | ||||||||||
Max. lifting height(mm) | 1600mm | 2000mm | 2500mm | 3000mm | 3500mm | 4000mm | |||||
Min. lifting height(mm) | ≤90 | ||||||||||
Vehicle closing height(mm) | 2060 | 1550 | 1800 | 2050 | 2300 | 2550 | |||||
Maximum height of vehicle(mm) | 2060 | 2530 | 3030 | 3530 | 4030 | 4530 | |||||
Fork form | Movable Type or Fixed Type | ||||||||||
Maximum outer width of fork(mm) | 680 SIZE CAN BE CUSTOMIZED | ||||||||||
Fork Length(mm) | 1000 | ||||||||||
Load centre distance(mm) | 500 | ||||||||||
Long(mm) | 1740 | ||||||||||
Width(mm) | 780 | ||||||||||
Frame Structure | single frame | Dural frame | |||||||||
Min. turning radius(mm) | 1430 | ||||||||||
Battery specifications(V/W) | DC12V/1.6 | ||||||||||
Storage Battery(V/Ah) | 12/120 | ||||||||||
Battery working time(H) | 4 | ||||||||||
Charger specifications(V/A) | input 220V/50HZ, output12V/15A Can be equipped with charging adapter | ||||||||||
net weight(kg) | 310 | 354 | 368 | 382 | 396 | 410 | |||||
Model | CTD.20/16 | CTD.20/20 | CTD.20/25 | CTD.20/30 | CTD.20/35 | CTD.20/40 | |||||
Load weight(kg) | 2000kg | ||||||||||
Max. lifting height(mm) | 1600mm | 2000mm | 2500mm | 3000mm | 3500mm | 4000mm | |||||
Min. lifting height(mm) | ≤90 | ||||||||||
Vehicle closing height(mm) | 2060 | 1550 | 1800 | 2050 | 2300 | 2550 | |||||
Maximum height of vehicle(mm) | 2060 | 2530 | 3030 | 3530 | 4030 | 4530 | |||||
Fork form | Movable Type or Fixed Type | ||||||||||
Maximum outer width of fork(mm) | 680 SIZE CAN BE CUSTOMIZED | ||||||||||
Fork Length(mm) | 1000 | ||||||||||
Load centre distance(mm) | 500 | ||||||||||
Long(mm) | 1740 | ||||||||||
Width(mm) | 780 | ||||||||||
Frame Structure | single frame | Dural frame | |||||||||
Min. turning radius(mm) | 1430 | ||||||||||
Battery specifications(V/W) | DC12V/1.6 | ||||||||||
Storage Battery(V/Ah) | 12/120 | ||||||||||
Battery working time(H) | 4 | ||||||||||
Charger specifications(V/A) | input 220V/50HZ, output12V/15A Can be equipped with charging adapter | ||||||||||
net weight(kg) | 310 | 354 | 368 | 382 | 396 | 410 | |||||
Recommend Products
Why Choose Us
Founded in 1997, Haizhili Machinery is a professional manufacturer of quality Material Handling Equipment.
We know exactly what you want. That’s why we only use the highest quality materials, and why we run our products through extensive tests before we add them to the Haizhili family.
Manufacturing Technique
1. Raw Material
2.Cutting Material
3.Stamping
4.Machining
5.Automatic Welding
6.Power Coatng
7.Assemble
8.Test
9.Packing
