China imported Cheap trailer 3 horse angle load Australian standard
- Category: >>>
- Supplier: Jinan Jinli Hydraulic Machinery Co. Ltd.
Share on (1600088456383):
Product Overview
Description
Product Overviews
China imported trailer 3 horse angle load Australian standard
The rub matting is the whole piece with nylon wire
All the rivets,nuts and bolts are stainless steel that waterproof
The board is made from African okoume hardwood
Our suspension is roll rocker tandem leaf spring
All the parts like Tied rings,locks,case hooks are all stainless steel
All the axles with electrical brake with break-away system
Removable divider ,fully padded
Australian standard
| MODEL :3HAL-D |
| 1. TRAILER MATERIALS |
| 1.1 CHASSIS MATERIAL double hot dip galvanized RHS(3.5mm-4.0mm) |
| 1.2 FRAME MATERIAL double hot dip galvanized RHS(2.5mm) |
| 1.3 BODY PANELgalvanized(1.2mm) |
| 1.4 ROOF special molded FRP 5475*1890*450mm |
| 1.5 NUTS & AMP ;BOLTS stainless steel |
| 2. WHEELS & TYPES |
| 2.1 WHEEL RIM 15' Iron rims |
| 2.2 TYPES 195R15C |
| 2.3 SPARE WHEEL one |
| 3.AXLES & SUSPENSIONS |
| 3.1 ALXES two special trailer axles |
| 3.2 LEAF SPRINGS roll rocker tandem spring suspension 6 plates |
| 3.3BRAKE AYATEM 4 wheel electic brakes with break - away systems |
| 4. WINDOWS & DOORS |
| 4.1 FRONT WINDOW 1220*610 |
| 4.2 SIDE WINDOWS 3 pop-up rectangle windows ,3 sliding rectangular windows |
| 4.3 ENTS three sash casement vent |
| 4.4 SIZE OF SIDE DOOR 1755*615 |
| 4.5 REAR UPPER DOOR 2020*1065 |
| 4.6 RAMP DOOR 2020*1210 |
| 4.7 REAR UPPER &RAMP DOOR STRUT high -intensity anti-rust strut |
| 4.8 HINGES FOR REAR UPPER DOOR special 6mm diameter copper hinges |
| 5. DRAWBAR |
| 5.1 DRAWBAR CHECKER PLATE 1.2mm aluminium |
| 5.2 DRAWBAR SAFETY CHAIN two |
| 5.3 BRACING WHEEL one |
| 6. LIGHTS &RETRO REFLECTORS |
| 6.1 TRAILER PLUGS square 7 wick plug |
| 6.2 SIDE LAMPS 6 |
| 6.3 REAR LAMPS LED group |
| 6.4 REAR LAMPS ATAND aluminium |
| 6.5 RETRO REFLECTIONS 6 |
| 7. MUDGUARD |
| 7.1 MUDGUARD TYPE compact mudguard |
| 7.2 mudguard checker plate 1.2mm aluminium in the front of mudguard |
| 7.3 pedal &aluminium step 1.2mm aluminium |
| 8. INTERIOR &EXTERIOR |
| 8.1 A KITCHEN with a cupboard and all appliance from yourself |
| 8.2 horse PROTECTION frame full padded |
| 8.3 horse ring six |
| 8.4 rubber matting for ramp door 10mm rubber matting |
| 8.5 BUBBER MATTING FOR FLOOR 10mm rubber matting |
| 8.6 RUBBER MATTING FOR INNER SIDE PANEL 6mm rubber matting |
| 8.7 WOOD BOARD FOR FLOOR & AMP ;RAMP DOOR 18mm hardwood plywood |
| 8.8 RUG RACK side |
| 8.9 SADDLE RACK in saddle box |
| 8.10 SADDLE BOX 1500mm height for 3 saddles |
| 8.11 PAINTING single or customized |
| 9. DIMENSIONS |
| 9.1 OVERALL DIMENSIONS (L*W*H:mm)6325*2280*2590 |
| 9.2 BODY DIMENSION(L*W*H:mm)5475*1980*2230 |
| 9.3 MAXIMUM INTERNAL DEMENSIONS :5450*1930*2155 |
