BRZHIFI AUDIO 50W linear regulated power supply with double output
BRZHIFI AUDIO 50W linear regulated power supply with double output
BRZHIFI AUDIO 50W linear regulated power supply with double output
BRZHIFI AUDIO 50W linear regulated power supply with double output
BRZHIFI AUDIO 50W linear regulated power supply with double output

BRZHIFI AUDIO 50W linear regulated power supply with double output

Share on:


Price:$39.60 - $42.75
Price in USD:Details

Quantity:


Product Overview

Description



The latest 50W linear regulated power supply, with TALEMA transformer, excellent performance, low noise, TL431 plus high power transistor discrete voltage stabilizing circuit, high speed and low resistance electrolytic capacitor and other materials for fever. This linear power supply is used to upgrade various audio devices, digital devices, mobile hard disk boxes, various CAD, wireless routers, fiber optic modules, set-top boxes, PC HiFi, notebook computers. The biggest highlight is the three-stage filter, the first-level EMI, the second-level capacitor array, and the third-level CLC. The output ripple is reduced to the lower
limit of the instrument test.
Size: 220*110*48mm.
Net weight: 1.6kg.
Weight after packing: 2.0kg.
The output voltage can be customized from DC 5V-24V, the maximum output current is 3.5A. Please leave information about how much voltage you need.
Output power plug size: 5.5*2.5mm.
This price is the standard version price, and you can choose the high version and black. Please contact me if you need




Output power plug size

5.5*2.5mm
Size
116*209*56mm
Net weight
1.5kg
Weight after packing
2.0kg
