3.9mm 3.4mm 2.8mm 2.7mm Lawn Mower Cable
US $0.10-$10.00
Low Smoke Zero Halogen BFOU RFOU Marine Offshore Shipboard Cable With Factory Price
- Category: Control Cables >>>
- Supplier: Zhengzhou,Huadong,Cable,Co.,Ltd.
Share on:
Product Overview
Description
High Voltage Power Cable XLPE Copper Power Cable 3 Core Cable Kable
Product Description
RFOU mud-resistant cable is ideal for the fixed installation of power, control and lighting circuits in both explosion EX and safe areas been halogen free and with an outer sheath that can withstand been exposed to mud and drilling and cleaning fluids.
600V/1,000V grade to IEC 60092-353, IEC 60754-1,2 IEC 60332-3/A and IEC 61034-1,2.
Cable Specification: RFOU power cable available in sizes 1.5m to 35mm. The cable features tinned, stranded copper conductor, etheylene propylene (EPR) insulated, halogen-free, mud-resistant bedding, tinned copper wire braid armour, SHF zero halogen and mud resistant sheath.
600V/1,000V grade to IEC 60092-353, IEC 60754-1,2 IEC 60332-3/A and IEC 61034-1,2.
Cable Specification: RFOU power cable available in sizes 1.5m to 35mm. The cable features tinned, stranded copper conductor, etheylene propylene (EPR) insulated, halogen-free, mud-resistant bedding, tinned copper wire braid armour, SHF zero halogen and mud resistant sheath.
R | EP-rubber, IEC 60092-360 (EPR) |
F | Inner covering,Flame retardant and halogen-free thermoset compound |
O/C | tinned copper wire braid/Galvanized steel wire braid |
U | Outer sheath, Flame retardant, halogen-free and mud resistant thermoset compound, SHF2 (IEC 60092-360) |
| Description | Unit | Offer |
| Conductor | - | Tinned Copper Wire Stranded |
| Diameter | mm | 1.2 |
| Insulation | - | HF-EPR |
| Color | - | Black/Blue |
| Thickness | mm | 0.6 |
| Pairs | mm | 4.8 |
| Wrapping | - | Polyester tape |
| Individual screen | - | Cu-mylar tape with Tinned copper drain wire |
| Inner bedding | - | SHF2 |
| Thickness | mm | 1.1 |
| Overall screen | - | Tinned copper wire braiding |
| Density Min. | % | 85 |
| Outer sheath | - | SHF2 |
| Nominal thickness | mm | 1.2 |
| Color | - | Black |
| Estimated Outer Diameter | mm | 13 |
| Approx.weight of complete cable | kg/km | 270 |
| Max. conductor resist. @20℃ | Ω/km | 26.7 |
Certifications
Production Flow
Our factory has advanced equipment of 20 sets production lines and 25 sets testing machinas, The production capacity is more than 12 million kilometers. We have skillful staff over 20-year experience,before starting working, every worker need to be trained professionally. Therefore, we can promise the product will be 100% quantified.
RFOU Marine cable Testing:
In our factory, every roll wire need to be test strictly, We wil test resistance, insulation thickness, the tension, stretch and so on. Before packing, every cable need to be test quantified, and we can make promise the 100% quantified.
Packaging & Shipping
RFOU Marine cable Package:
When you identify the details, don't forget to choose the package and its color. In usually, customer usually choose wooden drum and you can choose paint blue color, yellow color or red color. If you don't like these package or color, we can customize for you, now, you can send us your wanted package and colors.
RFOU Marine cable Delivery:
First of all, we will delivery on time. Especially in the busy season, we will word overtime to make sure delivery on time.
Secondary, about the loading, the cable will be protected well, all the needed measure will be adopted.
Thirdly, we have cooperated with profesional shipping agent and shipping company to keep you receive the intact on time.
Now you can send us the inquiry.
Buyer Feedback
We promise 100% quantified product, and we will also pay attentiont to package and delivery. Therefore, our customer can receive the perfect product. Come to start our business.
FAQ
1. The time you can get the quotation after the sending the inquiry
In the working time, our sales manager will send quotation to your email box within 1 or 2 hours. On the contrast, we will send you email within 12 hours. Therefore, email is needed to let us know, then we can contact with you.
2. For Sample
We can provide you the sample for free, if you want to check the cable, you can ask the sales manager.
3.Payment
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight
4. what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirement.
......
If you have any other question, you can send us inquiry, we will reply to you as soon as possible
