Fabric Cloth Excellent PTFE Plain Woven Weave Type Ptfe Coated Fiberglass Fabric Wall/roof Covering Cloth Customized Alkali Free
- Category: Fiberglass Cloth >>>
- Supplier: Taixing,Kaixin,Composite,Materials,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
PTFE fiberglass fabric
We start from fiberglass yarn, weave it into different thickness and width of fiberglass fabric, impregnated with fine PTFE-Teflon dispersion and dry it under 380℃ high temperature .
PTFE fiberglass fabric features:
high temperature resistance, its 24 hours temperature resistance is 260℃,maximum up to more than 300℃;
non-stick surface, easy to clean;
chemical resistance, anti corrosion;
flame retardant.
Applications:
Used as various of liners to resist high temperature, such as microwave liner, oven liner, or other liners .Used as non stick liner, intermediate, used as various conveyor belts, fusing belts, sealing belts, laminating fabric or anywhere need resist high temperature, non stick, chemical resistance etc, used as covering or wrapping material in petroleum, chemical industries, as wrapping material, insulating material, high temperature resistance material in electrical industries, desulfurizing material in power plant etc.
Related Products
ptfe/teflon adhesive fabric/tape
It is coated with silicone adheisve after deal with one side of the ptfe coated fabric.
ptfe /teflon baking mat
ptfe baking mat just made by the different thickness of ptfe fabric , which cut in different sizes according to customers'need.
Detailed Images
PTFE/Teflon coated fiberglass fabric /cloth | ||||||||||||
Item No. | Thickness | Max width | Nominal weight | Tensile Strength | Temperature Resistance | Color | ||||||
KB008 | 0.08mm±0.005 | 1250mm | 150g/㎡ | 550/450N/5cm | -70 to 260℃ | brown | ||||||
KB008W | 0.08mm±0.005 | 1250mm | 140g/㎡ | 550/450N/5cm | -70 to 260℃ | begie | ||||||
KB008B | 0.08mm±0.005 | 1250mm | 150g/㎡ | 550/450N/5cm | -70 to 260℃ | black | ||||||
KB0013 | 0.13mm±0.005 | 1250mm | 250g/㎡ | 1100/1000N/5cm | -70 to 260℃ | brown | ||||||
KB013B | 0.13mm±0.005 | 1250mm | 250g/㎡ | 1100/1000N/5cm | -70 to 260℃ | black | ||||||
KB015 | 0.15mm±0.005 | 1250mm | 300g/㎡ | 1200/1000N/5cm | -70 to 260℃ | brown | ||||||
KB018 | 0.18mm±0.001 | 1250mm | 380g/㎡ | 1800/1700N/5cm | -70 to 260℃ | brown | ||||||
KB018B | 0.18mm±0.001 | 1250mm | 380g/㎡ | 1800/1700N/5cm | -70 to 260℃ | black | ||||||
KB025 | 0.23mm±0.02 | 2600mm | 5000g/㎡ | 2100/1800N/5cm | -70 to 260℃ | brown | ||||||
KB025B | 0.25mm±0.02 | 2600mm | 500g/㎡ | 2100/1800N/5cm | -70 to 260℃ | black | ||||||
KB030 | 0.30mm±0.02 | 3000mm | 560g/㎡ | 2800/2400N/5cm | -70 to 260℃ | brown | ||||||
KB030B | 0.30mm±0.02 | 3000mm | 560g/㎡ | 2800/2400N/5cm | -70 to 260℃ | black | ||||||
KB035 | 0.35mm±0.02 | 3000mm | 640g/㎡ | 2600/2300N/5cm | -70 to 260℃ | brown | ||||||
KB035B | 0.35mm±0.02 | 3000mm | 640g/㎡ | 2600/2300N/5cm | -70 to 260℃ | black | ||||||
KB040 | 0.4mm±0.02 | 3000mm | 720g/㎡ | 3000/2500N/5cm | -70 to 260℃ | brown | ||||||
KB040B | 0.4mm±0.02 | 3000mm | 720g/㎡ | 3000/2500N/5cm | -70 to 260℃ | black | ||||||
KB050 | 0.55mm±0.02 | 3000mm | 840g/㎡ | 4400/4000N/5cm | -70 to 260℃ | brown | ||||||
KB065 | 0.65mm±0.02 | 3000mm | 1050g/㎡ | 5000/4800N/5cm | -70 to 260℃ | brown | ||||||
KB090 | 0.90mm±0.05 | 3000mm | 1550g/㎡ | 6000/5000N/5cm | -70 to 260℃ | brown | ||||||
KB090B | 0.90mm±0.05 | 3000mm | 1550g/㎡ | 6000/5000N/5cm | -70 to 260℃ | black | ||||||
Packing & Delivery
Packed with netural cartons, then packed with pallet. We also can packed according to customers' need if any request about the package.
We delivery depend on customzers' request. Usually if you are urgent on it, it will delivery by express, for the large quantity, delivery by air. And we will also delivery by sea for container which will much cheaper.
Our Company
FAQ
Question1:
Shall we have the sample?
Yes, we can send you the sample.
But we just can send A4 size free sample, and you should pay for the freightage yourself.
Question 2:
Can we printed the logo on the products?
It's depend on which products you need?We can print the logo on the silicone baking mat,but about the ptfe material products,we can print on the products,but it is easy to be removed.
Question 3:
Shall we paid by Western Union?
Yes, you can.
