OEM service PCB Prototype Fabrication multi layers print circuit board
- Category: Multilayer PCB >>>
- Supplier: Shenzhen,Fumax,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
PCB Specification
1 | Description | PCB Specification |
2 | Material | FR-4/HTG150-180 FR-4/CEM-1/CEM-3/Aluminum |
3 | Layer | 1-20 |
4 | Board Thickness | 0.2mm- 4.0mm |
5 | Board Thickness Tolerance | +/-10% |
6 | Copper thickness | 17.5um-175um (0.5oz-5oz) |
7 | Min Trace Width | 0.15mm |
8 | Min Space Width | 0.15mm |
9 | Min Drilling Dia | 0.2mm |
10 | PTH copper thickness | 0.4-2mil(10-50um) |
11 | Tolerance of Etching | ±1mil(±25um) |
12 | V-cut angle | 25°,30°,45°,60° |
13 | Pearl Strength of line | ≥ 6lb/in(≥ 107g/mm) |
14 | Impedance control and tolerance | 50Ω±10% |
15 | Twist&Wrap | ≤ 0.5% |
16 | Soldermask | Green, Red, Blue, White, Black, Yellow |
17 | Surface Finish/Plating | HASL/Lead Free HASL/OSP/Gold Plating/Immersion Gold/ENIG |
18 | File | Protel 99se/P-CAD/Autocad/Cam350 |
19 | Inner packing | Vacuum packing,Plastic bag |
20 | Outer packing | Standard carton packing |
Packaging & Shipping
Packaging
Packaging Detail: | Carton/Vacuum/Bubble bages, according to customer's requirement |
PCB Lead time
Items | Single/double side | 4 layer | 6 layer | Above 8 layer | HDI |
Sample lead time(Normal) | 5-6 | 6-7 | 7-8 | 10-12 | 15-20 |
Sample lead time(Fastest) | 48-72 hours | 5 | 6 | 6-7 | 12 |
Mass production lead time(First batch) | 7-9 | 10-12 | 13-15 | 16 | 20 |
Our Service
--Industry Designers
--Mechanical/Construction Engineers
--Mold/Tool Engineers
--Electronic Engineers
--Package Engineers
Company Information
Our Team
Factory Profile
Fumax is an Electronic Contract Manufacturing company which offers complete solutions for materials sourcing & procurement, PCBA (Printed Circuit Board Assembly), box building (plastic or metal enclosure), manufacturing and order shipment etc.Based on Shenzhen China, specialized in high Quality, low-to-high volume building, with quick response for New Product Introduction (NPI) and diverse products experience, Fumax serves as a reliable & flexbile manufacturing partner to customers worldwide and signaficantly optimizes our customers' operations and time to market
Purshase Tips:
1. PCBA Production
--Welcome any OEM and ODM service
--prototype/trial order: if you don't have the original gerber files, please just send us the original prototype for dupulication. We can copy it just from the real sample
--Mass order: Please send us the gerber files/schematic/bom list to run the mass production.Of course, first samples are going to be sent before the mass production. At the same time, we’ll contact you for any components change/alternative.
2. PCBA assembly:
--Layer:1 to 32 Layer
--Service:PCB production,pcba asssembly,components sourcing, complete product production like hard disk player
--SMT and DIP pcb assembly:SMT,Through-hole assembly,BGA....
--Leadtime: 15 to 35 days depending on the PCBA complicated.
--Test: full 100% PCB electrical test, PCBA function tested.
3. Quote requirement:
---You're much welcomed to send us any printed circuit board to check the quote. To make sure the price is more accurant, please kindly provide:
1) Gerber file and Bom list;
2) detailed pictures of finished pcba or the pcba sample;
3) Test method for PCBA
