High purity electronic insulation Alumina ceramic part
US $0.01-$0.10
Высокая прочность 99% алюминия Al2O3 квадратная Одиночная изогнутая керамическая пластина R400
- Category: Ceramics >>>
- Supplier: Xiamen,Wintrustek,Advanced,Materials,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
| - Material: | Silicon Carbide / Boron Carbide / Alumina |
| - Typical Characteristics: | 1. High Hardness 2. High Strength 3. Light Weight 4. High Impact Resistance 5. Good Toughness |
| - Available Shapes: | 1. Square Plates 2. Hexagonal Plates 3. Arc Plates 4. Curved Plates 5. Cylindrical Balls |
| - Protective Grade: | NIJ III / IV |
Material Properties
| Properties / Material | SiC | B4C | Alumina |
| Density (g/cm3) | 3.13 | 2.5 | 3.85 |
| Rockwell Hardness (HRA) | >93 | >93 | >88 |
| Vickers Hardness (kg/mm2) | >2650 | >2900 | >1600 |
| Modulus Of Elasticity (GPa) | >415 | >420 | >330 |
| Fracture Toughness (MPa.m1/2) | >4 | >4.5 | >2.5 |
| Flexural Strength (MPa) | >400 | >400 | >300 |
Regular Size
Production Process
Facilities
Packaging & Shipping
Buying Guides
In your inquiry, please provide as detailed imformation as you can for our evaluation.
1. Material:
If you are not sure what exact material you need, please tell us your requests on material performance and your specific application, according to which we will offer you the most suitable material.
2. Drawing:
Please make sure the drawing is clear with all of your technical requests so that we can quote asap.
3. Quantity:
The last but not the least, don't forget to tell us the quantity you need to get our best offer.
