650mAh + 2300mAh,Modular cell bin,Replace the battery without return.
2GBand
GSM900/GSM850/DCS1800/PCS1900
GPS&BDS Band
1573.42MHz&1561.098MHz
BLE Band
2.4GHz
Wi-Fi Band
2.4GHz
CPU
ARM7EJ-S 32Bit RISC
Network
GPS/WiFi&BLE/GSM
Storage Temperature
-40℃~85℃
Opreating Temperature
-25℃~55℃
BLE Covering range
<10M
Cold boot
< 1min
Warm boot
< 5s
GPS positionaI accuracy
< 5M
Waterproof rating
IP65
Housing material
Aluminium
Housing coloer
Black/Camouflage
Dimension
70mm(Diameter),142mm(Height)
Weight
~ 0.5Kg
Unlock manner
Bluetooth/Remote/Mechanical
Operating mode
Idle State/Energy-Saving mode/Regular mode
Battery capacity
2200mAh
2GBand
GSM900/GSM850/DCS1800/PCS1900
GPS&BDS Band
1573.42MHz&1561.098MHz
BLE Band
2.4GHz
Wi-Fi Band
2.4GHz
CPU
ARM7EJ-S 32Bit RISC
Network
GPS/WiFi&BLE/GSM
Storage temperature
-40℃~85℃
Operating temperature
-25℃~55℃
BLE Covering range
<10m
GPS Postion accuracy
< 5M
Waterproof rating
IP67
Housing material
Zinc
Housing color
Black/Silver
Dimension
140mm*64mm*30mm
Weight
~0.5Kg
On-off
>20000 times
Warranty
5 Years
Battery capacity
2000mah
Battery Voltage
3.6V
Standby Current
< 20ua
Operating Current
< 50ma(Motor working)
Relative humidity
40%-85%
Operating temperature
-20℃~75℃
Waterproof rating
IP67
Housing material
Zinc
Housing color
Black/silver
Dimension
100mm*60mm*23mm
Weight
approximately0.28kg
Q:How could we get samples? A:Samples testing are supported.we have samples stocks for demand.Please contact us to discuss how to send to you.OEM/ODM are welcomed.
Q:How much the Courier freight will be for the samples? A:We have unified pricing and operating instructions for regular samples. OEM products will need to be negotiated additionally.
Q:How can i get your price list? A:Please send us inquiry or TM to leave your request and company email to get quote in 24 hours.
Q:Can you arrange the transportation for us? A:Yes,We can arrange transportation by sea or by air.near port is Shenzhen port
Q:What's your usual payment term for orders? A:We accept terms of T/T / Westunion /Paypal /LC.
Q:How to Contact US?
Sales Engineer will follow you up after your inquiry.for direct contact.Please try:
