Product Overview

Description

Zircon Refractory Powder / Zircon Sand Wholesale Best Price



Zircon chemical formula: ZrSiO4, also known as zircon, zircon sand. It is a mineral consisting mainly of zirconium, silicon, and oxygen that is crystallized from the magma at the time of the formation of igneous rocks. It is a high quality refractory. The theoretical composition of zircon sand is: ZrO2:67.1%; SiO2:32.9%. Zircon sand is pure colorless and transparent crystal, often because of quantity and species of different origin and different impurities dyed yellow, orange, red and brown color, Mo type hardness of 7.8, the proportion of the refractive index of 1.93-2.01, 4.6-4.71g/cm fand, melting point of 2550 DEG C or above.



Pure zircon sands usually appear as colorless and transparent tetrahedral prismcrystals, because of different origins, the types and quantities of impurities. It is often dyed into yellow, orange, red, brown and other colors.

It usually has a mineral paragenesis with ilmenite, rutile, monazite, xenotime in beach placer, which can be obtained through the water gravity selection, electric separation, magnetic separation and other mineral processing methods, the theoretical components are ZrO2 and SiO2, and small amount of Fe2O3, CaO, Al2O3 and other impurities. In theory, pure zicon sands contains 67.23% and 32.77% SiO2.



Product name	Zircon sand
MF	ZrSiO4
Specific gravity	4.68-4.71
Bulk density	170-180 lb/ft3; 2700kg/m3;
Hardness	7.8 Moh
Angle of repose	30 degree
Melting point	4000°F, 2550°c
Refractive index	1.93 to 2.01
Thermal stability	no change to 3090°F, 1700°c
Loss on ignition	0.02%-0.12%
Color	Colorless transparent crystal
Place of origin	Thailand
Loading port	Laem Chabang port
Delivery time	7-14 days after payment





Chemical Composition



Grade	(Zr.Hf)O2	TiO2	Fe2O3	Al2O3	SiO2
Super	≥66	≤0.06	≤0.08	≤1.0	≤32
Grade 1	≥65	≤0.15	≤0.1	≤1.0	≤34
Grade 2	≥63	≤0.5	≤0.3	≤1.0	≤34
Grade 3	≤63	≤0.5	≤0.3	≤1.0	≤34
Grade 4	≥60	≤3.5	≤0.8	≤1.2	≤32
Grade 5	≥55	≤8.0	≤1.5	≤1.5	≤31



Technical Specifications
Hardness: 7-8	Specific gravity: 4.6-4.71
Refractive index: 1.93-2.1	Melting point: 2550°C
Birefringence	Direct asbsorbance of light
Low magnetic susceptibility	Electrical insulation



Application:

Zircon sand used for refractory material (zirconium refractory material, such as corundum brick, zirconium refractory fiber), sand mold casting industry (precision casting sand), precision enamelware, also used in glass, metal (sponge zirconium and zirconium compounds (two) zirconium oxide, zirconium oxychloride, zirconate sodium, potassium zirconium fluoride, etc.) in the production of zirconium sulfate. A small amount of zircon sand is used for iron alloy, medicine, paint, leather, abrasive, chemical and nuclear industry. A very small amount of metal is used to smelt zirconium.



1.The mold coating and the ceramic core used in the mold casting industry. Zircon sand can be used as a quality raw sand for casting, and zircon sand powder is the main component of casting paint. Zircon sand has the characteristics of good thermal conductivity, low and high thermal expansion rate,but compared with other common refractory materials it has high chemical stability, so the quality of zircon and other various adhesives with good adhesion and used in foundry industry.



2.zircon sand is the main material in ceramic industry, also used for glazing, zirconium silicate with high refractive index, stable chemical performance, widely used in a variety of architectural ceramics, sanitary ceramics, daily-use ceramics, a ceramic crafts such as production, processing the production of ceramic glaze, the use of a wide range of applications, a large amount of. Zirconium silicate is widely used in ceramic production.



3.Zircon sand is a high quality industrial additive. The output of computers and TV sets is increasing rapidly, and the glass panel with zircon sand is used as an additive to improve its refractive index. Zirconium silicate has also been further applied in the production of emulsion glass, the television industry and in the color picture tube and glass industry.



4.Zircon sand is the main raw material for the preparation of zirconium ZrO2, hafnium and a variety of zirconium products. Zircon sand is also used in glass furnace zircon brick, ladle zircon brick, ramming material, coating and casting material.



5. zircon sand has a special use in many chemical industries, including cosmetics, cement, food corrosion, leather, fiber (used in the manufacture of flame retardant fiber).



6. zircon sand and zircon powder are mixed with other refractory materials for other purposes. Zircon sand added to other materials can improve its properties. For example, adding zircon sand into cordierite can broaden the sintering range of cordierite without affecting its thermal shock stability. With the addition of zircon sand in the high alumina brick, the anti peeling and high alumina brick is made, and the thermal shock stability is greatly improved.



Packing Details



- 25kg (55lb)/bag

- 40 bags packed in a 1000kg (2200lb) bulk bag or pallet.

- 1000kg (2200lb)/jumbo bag

- As customer's requirement



For more information about the product, please feel free to contact us.
