SIM card dispenser with barcode scanner PT F1
- Category: Payment Kiosks >>>
- Supplier: Shenzhen Prova Tech Co. Ltd.
Share on (1600108279232):
Product Overview
Description
Product Description
Product performance description:
PT-F1-1xxx series card dispenser is a high-performance card issuing device which primarily dispenses paper tickets and PVC cards to users according to instructions from HOST. It is primarily applicable to self-service terminals such as parking lot management
system, expressway toll gate, self-service charging system, self-service card vending terminal, etc.
system, expressway toll gate, self-service charging system, self-service card vending terminal, etc.
Features:
5.1.Unique dispensing wheel design: is capable of issuing various embossing cards accurately.
5.2.Convenient and simple card adjustment design:
is stable and accurate to dispense cards with various thicknesses.
5.3.Compact structure design: effectively saves space for the complete machine.
5.4.Rear card capture box: provides convenience for card management.
5.5.Simple collection channel design: satisfies user requirement for large collection amount.
5.6.Multiple sensors: are able to judge the card position and indicate the card status.
5.7.Scientific card transfer wheel design: automatically avoids dust accumulation which will lead to slippage.
5.8.Multiple levels of sensor circuit protection: prevents optical interference.
5.9.Supports multiple communications (max. 16 C/Ds).
5.10.Supports online upgrade program.
5.1.Unique dispensing wheel design: is capable of issuing various embossing cards accurately.
5.2.Convenient and simple card adjustment design:
is stable and accurate to dispense cards with various thicknesses.
5.3.Compact structure design: effectively saves space for the complete machine.
5.4.Rear card capture box: provides convenience for card management.
5.5.Simple collection channel design: satisfies user requirement for large collection amount.
5.6.Multiple sensors: are able to judge the card position and indicate the card status.
5.7.Scientific card transfer wheel design: automatically avoids dust accumulation which will lead to slippage.
5.8.Multiple levels of sensor circuit protection: prevents optical interference.
5.9.Supports multiple communications (max. 16 C/Ds).
5.10.Supports online upgrade program.
Technical Features:
■ Support card
1. Card size: width: 55 mm, length: 86 mm
2. Thickness: 0.2mm--1.2mm (factory standard 0.8mm)
■ Communication method
RS232 / TTL optional
(RS232 supports multi-machine communication, the factory address defaults to 00)
■ Working conditions:
Working voltage: DC24V±5%
Quiescent current: less than 200mA
Maximum working current: 2.5A
Default baud rate: 9600 bits per second
■ Card stacker load
Standard 0.76mm thickness non-embossed card loading capacity: 155 pcs
Embossed card loading capacity: 100 pcs
■ Recycling bin capacity
Standard card capacity is 25
(Customizable recycling channel for unlimited card collection)
■ Life
Issuing life: ＞1,000,000 times
■ Environmental conditions
Working temperature/humidity: -10℃--60℃/0-90% (no condensation)
Storage temperature/humidity: -30℃—70℃/0—90% (no condensation)
■ Net Weight
Approx. 1.6KG
* Package dimensions
Single packaging box length×width×height (mm): 495 × 275 × 290
■ Support card
1. Card size: width: 55 mm, length: 86 mm
2. Thickness: 0.2mm--1.2mm (factory standard 0.8mm)
■ Communication method
RS232 / TTL optional
(RS232 supports multi-machine communication, the factory address defaults to 00)
■ Working conditions:
Working voltage: DC24V±5%
Quiescent current: less than 200mA
Maximum working current: 2.5A
Default baud rate: 9600 bits per second
■ Card stacker load
Standard 0.76mm thickness non-embossed card loading capacity: 155 pcs
Embossed card loading capacity: 100 pcs
■ Recycling bin capacity
Standard card capacity is 25
(Customizable recycling channel for unlimited card collection)
■ Life
Issuing life: ＞1,000,000 times
■ Environmental conditions
Working temperature/humidity: -10℃--60℃/0-90% (no condensation)
Storage temperature/humidity: -30℃—70℃/0—90% (no condensation)
■ Net Weight
Approx. 1.6KG
* Package dimensions
Single packaging box length×width×height (mm): 495 × 275 × 290
Details Images
Related Products
FAQ
1. Could I have prices of your products?
Welcome. Pls feel free to send us an email here. You will get our reply in 24 hours
2. Can we print our logo/website/company name on products?
Yes, please advise the size and Pantone Code of the logo.
3. What's the lead time for regular order?
14-21 days for order quantity lower than 500pc; For more quantity, usually 30 days.
4. Can I get a discount?
Yes, for the order quantity more than 100 pcs, please contact us to get the best price.
5. Do you inspect the finished products?
Yes, each step of production and finished products will be came out inspection by QC department before shipping.
Welcome. Pls feel free to send us an email here. You will get our reply in 24 hours
2. Can we print our logo/website/company name on products?
Yes, please advise the size and Pantone Code of the logo.
3. What's the lead time for regular order?
14-21 days for order quantity lower than 500pc; For more quantity, usually 30 days.
4. Can I get a discount?
Yes, for the order quantity more than 100 pcs, please contact us to get the best price.
5. Do you inspect the finished products?
Yes, each step of production and finished products will be came out inspection by QC department before shipping.
