Indoor p1.5 p2 p2.5 p3 p3.91 500x500 die casting aluminum stage advertising panel display led screen
- Category: >>>
- Supplier: Shenzhen DDW Technology Co. Ltd.
Share on (1600112036548):
Product Overview
Description
Model | P2.604 | P2.976 | P3.91 | P4.81 | P5.95 |
Module size(mm) | 250x250 | 250x250 | 250x250 | 250x250 | 250x250 |
Module resolution (dot) | 96x96 | 84x84 | 64x64 | 52x52 | 42x42 |
Scanning | 1/32S | 1/28S | 1/16S | 1/13S | 1/7S |
SMD | 1G1R1B | 1G1R1B | 1G1R1B | 1G1R1B | 1G1R1B |
Maintenance | Front/Back | Front/Back | Front/Back | Front/Back | Front/Back |
Installation | Hanging/streching | Hanging/streching | Hanging/streching | Hanging/streching | Hanging/streching |
Cabinet size(mm) | 500x500/500x1000 | 500x500/500x1000 | 500x500/500x1000 | 500x500/500x1000 | 500x500/500x1000 |
Density(dot/㎡) | 147456 | 112896 | 65536 | 43264 | 28224 |
Brightness(cd/㎡) | 800-1200 | 800-1200/3200-3800 | 800-1200/3500-4200 | 800-1200/3500-4200 | 800-1200/3800-4200 |
Max. Power Consumption | 800 | 800 | 800 | 800 | 600 |
Average Power Consumption | 400 | 400 | 400 | 400 | 300 |
Cabinet weight (kg) | 7.5kg | 7.5kg | 7.5kg | 7.5kg | 7.5kg |
Cabinet material | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum |
IP rate | IP31 | IP31/IP65 | IP31/IP65 | IP31/IP65 | IP65 |
Grayscale | 10000:1 | 10000:1 | 10000:1 | 10000:1 | 10000:1 |
Refresh rate(hz) | 1920-3840 | 1920-3840 | 1920-3840 | 1920-3840 | 1920-3840 |
Frame change frequency | 50/60hz | 50/60hz | 50/60hz | 50/60hz | 50/60hz |
Horizontal viewing angle | >140° | >140° | >140° | >140° | >140° |
Vertical viewing angle | >140° | >140° | >140° | >140° | >140° |
Best viewing distance | >2.6m | >3m | >4m | >5m | >6m |
Input Voltage | AC110V - AC220V | AC110V - AC220V | AC110V - AC220V | AC110V - AC220V | AC110V - AC220V |
Module Max. current | 5.0-7.0 | 5.0-7.0 | 6.0-7.5 | 5.5-7.0 | 5.5-7.0 |
Temperature-operating | ﹣10℃～60℃ | ﹣10℃～60℃ | ﹣10℃～60℃ | ﹣10℃～60℃ | ﹣10℃～60℃ |
Humidity-operating | 10%～90% | 10%～90% | 10%～90% | 10%～90% | 10%～90% |
Life span (H) | ≥100,000 | ≥100,000 | ≥100,000 | ≥100,000 | ≥100,000 |
MTBF (H) | >10,000 | >10,000 | >10,000 | >10,000 | >10,000 |
