Product Overview
Description
EPS Foam Crusher Cutter Recycling Machine
Application:
Our EPS hot melter recycling machine adopts manual feeding,thematerial will be crushed by the four shaft blades and conveywd to the barrel of the main machine through the screen.This screw of the main machine can convey the heat the material to melt condition,then and air jam bladecut them to pieces for easy storage and transportation.
Feature:
1. Adopting deafener low in noise.
2. Adopting removable blades which can be separately removed and sharpened after getting blunt.
3. Suitbale for smashing all kinds of soft ,hard and foamed plastics.
4. Easy to operate and high output
Processing Method:
The operator firstly runs the heating system to pre-heat the screw to reach rated temperature, and then throws plastic waste into hopper of the machine, and then the pre-breaker with two rotating knife shafts will crush it into 10~50mm pieces, which are forced by a screw into the extruder system.
Model | CF-HM-50 | CF-HM-100 | CF-HM-200 |
Feeding Size | 400mmx460mm | 650mmx400mm | - |
Screw Diameter | φ80mm | φ138mm | φ197mm |
Screw Length | 1090mm | 1090mm | 150mm |
Screw Speed | 100rpm | 165rpm | 110rpm |
Extrusion center height | 300mm | 250mm | 326mm |
Heating power | 2.7KW | 3KW | 3 zones total 10KW |
Main motor power | 1.1KW | 7.5KW | 15KW |
Crusher Motor | 1.1KW | - | 2.2KWx2 |
Screen Size | 30mm | 40mm | 40mm |
Blade rotation diameter | 290mm | 250mm | - |
Blades quantity | 7 sets | 12 sets | Twin screw 9sets+10sets |
Blades rotation speed | 120rpm | 150rpm | 100rpm |
Size | 1400x700x1500mm | 1200x1000x1400mm | 2800x1580x1950mm |
Capacity | 15-20kg/h | 50kg/h | 100-120kg/h |
