5-87813178-b Excavator Engine Liner Kit for ISUZU 6WG1 4HK1 6HK1 4JB1
US $100.00-$250.00
11.5VC500 VC clutch Parts Side Plate Engine Parts China Manufacturer Machinery Pneumatic Parts
- Category: Machinery Engines & Parts >>>
- Supplier: Henan,Dalin,Rubber,And,Telecommunications,Apparatus,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
At present, in the mining, petroleum, chemical, electric power, metallurgy, shipbuilding and other industries, hundreds of kilowatts or even thousands of kilowatts of electric motors or internal combustion engines are widely used to drive heavy equipment loads.
The VC Clutch is 100% interchangeable with Eaton Airflex or Petroleum Industry Machinery.
Standard Sizes:
Narrow Sizes: 11.5VC500, 14VC500, 16VC500, 20VC600, 24VC650, 28VC650, 33VC650, 35VC650, 37VC650, 42VC650
Wide Sizes: 14VC1000, 16VC1000, 20VC1000, 24VC1000, 28VC1000, 32VC1000, 38VC1200, 42VC1200, 46VC1200, 52VC1200, 51VC1600, 60VC1600, 66VC1600
Standard Sizes:
Narrow Sizes: 11.5VC500, 14VC500, 16VC500, 20VC600, 24VC650, 28VC650, 33VC650, 35VC650, 37VC650, 42VC650
Wide Sizes: 14VC1000, 16VC1000, 20VC1000, 24VC1000, 28VC1000, 32VC1000, 38VC1200, 42VC1200, 46VC1200, 52VC1200, 51VC1600, 60VC1600, 66VC1600
Where used:
1.Grinding Mills
2.Marine Propulsion
3.Metal Forming Machinery
4.Oil Field Machinery
5.VC series
1.Grinding Mills
2.Marine Propulsion
3.Metal Forming Machinery
4.Oil Field Machinery
5.VC series
Friction shoe backing plates have large air passages through their entire length. This construction coupled with scalloped side plates allows cooling air to flow through the element.In addition, the large exposed inside diameter assures the coolest possible operation. None of the heat is generated deep
in the element's internal parts where it can be trapped. The open construction assures rapid heat dissipation.
in the element's internal parts where it can be trapped. The open construction assures rapid heat dissipation.
Description of application effect
VC Clutch：
Ventilated pneumatic clutch is a kind of pneumatic clutch with excellent performance developed on the basis of common pneumatic clutch. It has good ventilation and heat dissipation, the pneumatic tire does not bear torque, and it is stable to hang and detach, thus it has higher working performance and service life than the common type.
Ventilated pneumatic clutch is a kind of pneumatic clutch with excellent performance developed on the basis of common pneumatic clutch. It has good ventilation and heat dissipation, the pneumatic tire does not bear torque, and it is stable to hang and detach, thus it has higher working performance and service life than the common type.
Detailed Images
The type VC element assembly is specifically designed and built for severe clutch or brake applications in which large inertia loads and sustained slippage would normally result in loss of torque and reduced operating life.
Size Information
Size | Torque Rating | Maximum Speed | Moment of inertia | Weight | Friction Area |
11.5VC500 | 3050 | 1800 | 1.81 | 43 | 1071 |
14VC500 | 4430 | 1500 | 3.28 | 58 | 1322 |
16VC600 | 7350 | 1400 | 4.83 | 68 | 1825 |
20VC600 | 10500 | 1200 | 8.11 | 81 | 2451 |
24VC650 | 15300 | 1050 | 15.50 | 111 | 3006 |
28VC650 | 20600 | 1000 | 22.55 | 127 | 3535 |
33VC650 | 28800 | 900 | 45.49 | 178 | 4147 |
37VC650 | 36200 | 800 | 58.80 | 196 | 4644 |
42VC650 | 42900 | 800 | 83.58 | 220 | 5302 |
SI | N.m/@5.2bar | rpm | kg.m2 | kg | cm2 |
