How Solar Powered Pool Ionizer Works
As solar pool ionizer floats on the pool, sunlight is converted into electricity by the photovoltaic panel. This harmless low current energizes a special alloyed mineral electrode below water line, causing the release of mineral ions into the water, ionized water eliminates the growth of microorganism.
Functions of Solar Powered Pool Ionizer
(1) Inhabit the growth of algae.
(2) Reduce the use of chlorine by about 85%-95%.
(3) Sterilize the bacteria .
(4) Balance the pool mineral ions
Specifications of Solar Powered Pool Ionizer
Item Name | solar powered pool ionizer |
Model | YQ-P002 |
:Solar panel | 2W laminated |
Electrode | special alloyed with high content copper ion |
Spring | high grade stainless steel |
Floating Plate | diameter 200 mm , high density , anti-UV ABS |
Copper Test kits | 30pcs / bottle |
Filter screen & screw | Nylon |
Electrode using time | 1-2 summer season |
Maximum pool size | 32000 gallon |
Warranty | 2 year |
Feature of Our Solar Powered Pool Ionizer
1. Take special method to prevent the water entering into the product.
2. Filter screen:can prevent the residues on the electrode from falling into the pool , keep it clean.
3. High grade stainless steel spring , fixed , rustless under water
4. Special alloyed electrode with high efficiency , can be used about 1-2 summer season .
5. Laminated 2w solar panel with tempered glass , strong & long lifespan.
6. Offer 2 years warranty.
7. Save energy and chemical cost , safe and healthy to our body , little maintainence and simple
installation .
Solar powered pool ionizer test report by Pony Testing International Group
Test Items | Unit | Before Treatment | After Treatment |
Total Coli Form Group | MPN/100 ml | 9.2×10^6 | <2 |
Total Number of Bacterial Colony | CFU/ml | 1.3×10^6 | 125 |
Copper | mg/L | 0.008 | 0.942 |
PH |
| 7.82 | 7.14 |
Temperature | ℃ | 21 | 21 |
Total Alkalinity (Calcium Carbonate) | mg/L | 105 | 85.0 |
Free Residual Chlorine | mg/L | <0.53 | <0.05 |
Cah (Calcium Carbonate) | mg/L | 133 | 124 |
How to Use and maintain Solar Powered Pool Ionizer
1. Float the solar powered pool ionizer on the pool .
2. Test the pool copper ion level weekly. If excess 0.9 ppm, take it out from the pool,
and put it back when less than 0.5 ppm.
3. Use brush to wash away the residues on the electrode , to make it work efficienctly.
