AkuSense MD18 35V ultrasonic water tank level sensor best water level iot ultrasonic sensor sensor waterproof
- Category: >>>
- Supplier: Shenzhen Akusense Technology Co. Ltd. [Guangdong China]Shenzhen
Share on (1600131248780):
Product Overview
Description
Model No. | MD18-35V |
Sensing type | Diffuse reflection |
Working range | 50~400 mm |
Sensing range | 350 mm |
Reproducibility max. | 1 mm |
linearity error | 5 mm |
Resolution | 0.1mm |
Ultrasonic frequency | 300 kHz |
Opening angle | <12° |
Service life(Tu=+25℃) | 100000 h |
Switch hysteresis | 2 mm |
Supply voltage | 18~30 V DC |
Current consumption(Ub=24V) | <30mA |
Switch frequency | 20 Hz |
Response time | 25 ms |
Temperature range | -25~+60℃ |
Switch outputs | 1 |
Switch output voltage drop | <2.5V |
PNP switch output/ switch current | 100 mA |
Analog output | 0~10V |
Synchronous mode | Up to 40 sensors |
Short circuit protection | Yes |
Reverse polarity protection | Yes |
Overload protection | Yes |
Lockable | Yes |
Interface | IO-Link |
IO-Link version | 1.0 |
Protection class | Class 3 |
Setting method | Teach-in display |
Material | Stainless steel |
Full encapsulation | Yes |
Degree of protection | IP67 |
Connection | M12*1; 4/5 Pin |
PNP NO/ NC switchable | Yes |
Specification
Cylindrical M18 Metal housing series
● Selectable M18 and M30
● Sensing distance varies from 40 to 6000mm
● Various output type from NPN/PNP/Analog voltage/Analog current to choose from
● Sensing distance varies from 40 to 6000mm
● Various output type from NPN/PNP/Analog voltage/Analog current to choose from
